057 - Rear Suspension - Arms And Stabiliser Bar

000 - Spare Assembly Units

001 - Crankcase

002 - Crankase - Covers

003 - Crankshaft - Connecting Rods And Pistons

004 - Right Hand Cylinder Head

005 - Left Hand Cylinder Head

006 - Timing System - Drive

007 - Timing - Valves

008 - Engine Covers

009 - Fuel System

010 - Fuel Pump

011 - Fuel Tank - Filler Neck And Pipes

012 - Fuel Tank - Insulation And Protection

013 - Evaporative Emissions Control System

014 - Injection - Ignition System

015 - Pneumatic Actuator System

016 - Secondary Air System

017 - Intake Manifold

018 - Air Intake

019 - Front Exhaust System

020 - Rear Exhaust System

021 - Bypass Valve Control System -Hgtc And Hgts Versions- -Optional- -Applicable From Ass. No. 62511-

022 - Blow-By System

023 - Lubrication System - Tank

024 - Lubrication - Oil Pumps

025 - Lubrication - Oil Sump And Filters

026 - Cooling System - Radiator And Header Tank

027 - Water Pump

028 - Clutch And Controls -Not For F1-

029 - Clutch And Controls -Applicable For F1-

030 - Clutch And Controls -Applicable For "Oto"-

031 - Gearbox Housing

032 - Differential Case And Gearbox Cooling Radiator

033 - Primary Gearbox Shaft Gears And Gearbox Oil Pump

034 - Secondary Gearbox Shaft Gears

035 - Internal Gearbox Controls -Not For F1-

036 - Internal Gearbox Controls -Applicable For F1-

037 - External Gearbox Controls

038 - Engine/Gearbox Connector Pipe And Insulation

039 - Differential And Axle Shaft

040 - Hydraulic Brake And Clutch Control

041 - Electronic Accelerator Pedal

042 - Pedal Board

043 - F1 Clutch Hydraulic Control -Applicable For F1-

044 - Power Unit And Tank -Applicable For F1-

045 - Brake System -Not Applicable For Gd-

046 - Brake System -Applicable For Gd-

047 - Front Brake Calliper

048 - Rear Brake Calliper

049 - Parking Brake Control

050 - Hydraulic Power Steering Box

051 - Hydraulic Fluid Reservoir For Power Steering System And Coil

052 - Steering Control

053 - Power Steering Pump

054 - Front Suspension - Shock Absorber And Brake Disc

055 - Front Suspension - Arms And Stabiliser Bar

056 - Rear Suspension - Shock Absorber And Brake Disc

057 - Rear Suspension - Arms And Stabiliser Bar

058 - Wheels

059 - Tyre Pressure Monitoring System

060 - Battery

061 - Alternator - Starter Motor - Ac Compressor

062 - Ac System - Freon Pipes

063 - Ac System - Water Pipes

064 - Evaporator Unit And Controls

065 - Tools Provided With Vehicle

066 - Documentation And Accessories

067 - Spare Wheel And Accessories -Optional-

068 - Spare Wheel And Tool Bag Fasteners

100 - Bodyshell - External Trim

101 - Bodyshell - Roof

102 - Structures And Elements, Front Of Vehicle

103 - Structures And Elements, Centre Of Vehicle

104 - Structures And Elements, Rear Of Vehicle

105 - Flat Undertray And Wheelhouses

106 - Front Bumper

107 - Rear Bumper

108 - Engine Compartment Firewall Insulation

109 - Passenger Compartment Insulation

110 - Luggage Compartment Insulation

111 - Passenger Compartment Trim And Mats

112 - Headliner Trim And Accessories

113 - Luggage Compartment Trim

114 - Engine Compartment Lid

115 - Luggage Compartment Lid And Fuel Filler Flap

116 - Doors - Substructure And Trim

117 - Doors - Opening Mechanism And Hinges

118 - Doors - Power Windows And Rear-View Mirror

119 - Screens, Windows And Seals

120 - Electric Front Seat - Trim And Accessories

121 - Electric Front Seat - Seat Belts And Devices

122 - Rear Seat - Seat Belts

123 - Tunnel - Substructure And Accessories -Not For "Oto"-

124 - Tunnel - Substructure And Accessories -Applicable For "Oto"-

125 - Dashboard

126 - Glove Compartment

127 - Airbag

128 - Instrumentation

129 - Headlights And Taillights

130 - Exterior Trim

131 - Electrical System

132 - Acceleration Sensors

133 - Engine Compartment Ecus

134 - Passenger Compartment Ecus

135 - Luggage Compartment Ecus

136 - Antitheft System Ecus And Devices

137 - Audio - Gps System

138 - Pro Online Telephone-Gps Module

139 - Audio System - Enhanced Version

140 - Windscreen Wiper, Windscreen Washer And Horns

141 - Adhesive Labels And Plaques

142 - PAINTING -Applicable for S.T. Schedule only-

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	207582	Upper Suspension Lever No longer supplied- -Replaced by 200945	-	2	POA (Exc VAT)	?	0
1	200945	Upper Suspension Lever	-	2	£427.14 (Exc VAT)	?	0
2	179555	Compensator Ring Bushing	-	2	£3.32 (Exc VAT)		0
3	171848	Rubber Boot And Clip	-	4	£75.32 (Exc VAT)		0
4	190274	Spacer	-	2	£11.09 (Exc VAT)		0
5	188581	Screw M10 x 1.25x 83.5 TCEI	-	2	£16.17 (Exc VAT)		0
6	194801	Silentbloc Bush Replace as a pair- -Applicable until depletion	-	4	POA (Exc VAT)		0
6	209167	Silentbloc Bush Replace as a pair	-	4	£169.55 (Exc VAT)		0
7	170155	Stud 8mmx50mm	-	14	£13.46 (Exc VAT)		0
8	104030	Nyloc Nut M8 x 1.25 x 9.5	-	8	£0.20 (Exc VAT)		0
9	14496524	Washer	-	8	£0.09 (Exc VAT)		0
10	124338	Washer D. 8 - 25 x 3 No longer supplied- -Replaced by 219344	-	8	£5.99 (Exc VAT)	?	0
	Superseded by 219344	Washer D8.5x24x	N	8	£0.24 (Exc VAT)		0
10	219344	Washer D8.5x24x	-	8	£0.24 (Exc VAT)		0
11	13582210	Thread Inserts 8mm	-	14	POA (Exc VAT)	?	0
12	190272	Screw M12 x 1.25 x 86	-	2	£23.38 (Exc VAT)		0
13	190750	RH Rear Knuckle	-	1	£757.23 (Exc VAT)	?	0
13	220454	RH Rear Knuckle Version with CCM brakes- -Optional	-	1	£939.32 (Exc VAT)	?	0
13	190751	LH Rear Knuckle	-	1	£892.98 (Exc VAT)	?	0
13	220453	LH Rear Knuckle Version with CCM brakes- -Optional	R -	1	£894.59 (Exc VAT)	?	0
14	207581	Lower Rear Suspension Lever	-	2	£728.41 (Exc VAT)		0
15	171847	Rubber Boot And Clip	-	4	£75.32 (Exc VAT)	?	0
	Alternative 171847/A	Rubber Boot And Clip	MP N	4	£55.99 (Exc VAT)		0
16	190273	Spacer	-	2	£30.84 (Exc VAT)	?	0
17	179554	Compensator Ring Bushing	-	2	£3.43 (Exc VAT)		0
18	196789	Silentbloc Bush	-	4	£178.83 (Exc VAT)		0
19	182215	Screw	-	8	POA (Exc VAT)	?	0
20	14496624	Washer D. 10.50-21 x2	-	8	£0.05 (Exc VAT)		0
21	200938	Spacer Installed if necessary	-	8	£1.89 (Exc VAT)	?	0
21	203312	Spacer 1mm Installed if necessary	-	8	£6.64 (Exc VAT)	?	0
21	203313	Spacer 1.5mm Installed if necessary	-	8	£50.48 (Exc VAT)		0
21	203314	Spacer 2mm Installed if necessary	-	8	£1.89 (Exc VAT)	?	0
21	203315	Spacer 2.5mm Installed if necessary	-	8	£18.99 (Exc VAT)		0
21	203316	Spacer 3mm Installed if necessary	-	8	£50.48 (Exc VAT)		0
22	194792	Tie Rod No longer supplied- -Replaced by 252479	-	2	POA (Exc VAT)	?	0
22	252479	Tie Rod	-	2	£421.42 (Exc VAT)		0
23	194794	Tie Rod Joint Applicable for tie-rod Part No. 194792	-	2	£239.70 (Exc VAT)		0
24	204248	Nut Applicable for tie-rod Part No. 194792	-	2	£33.14 (Exc VAT)		0
25	104030	Nyloc Nut M8 x 1.25 x 9.5	-	6	£0.20 (Exc VAT)		0
26	12647604	Washer No longer supplied- -Replaced by 113113	-	6	£0.05 (Exc VAT)	?	0
26	113113	Washer 8mm hole	MP -	6	£4.35 (Exc VAT)		0
27	179556	Bolt For Track Rod Joint	-	2	£43.60 (Exc VAT)		0
28	168993	Roll Bar Link	-	2	£53.70 (Exc VAT)	?	0
29	12164714	Nut M10 x 1.25 x 8	-	2	£0.34 (Exc VAT)		0
30	12601474	Wavy Washer 10mm	-	2	£0.03 (Exc VAT)		0
31	199593	Rear Anti Roll Bar Applicable until depletion	-	1	POA (Exc VAT)	?	0
31	252344	Rear Anti Roll Bar Applicable after depletion of 199593	-	1	£231.74 (Exc VAT)	?	0
31	235230	Rear Anti Roll Bar Enhanced version	-	1	POA (Exc VAT)	?	0
32	196385	Stabiliser Bar Bush	-	2	£27.34 (Exc VAT)	?	0
32	200656	Stabiliser Bar Bush D.23.5x43 Enhanced version	-	2	£12.98 (Exc VAT)		0
33	133802	Roll Bar Bracket No longer supplied- -Replaced by 239775	-	2	£78.59 (Exc VAT)		0
33	239775	Roll Bar Bracket	-	2	£19.25 (Exc VAT)	?	0
	Superseded by 133802	Roll Bar Bracket	N	2	£78.59 (Exc VAT)		0
34	113113	Washer 8mm hole	MP -	4	£4.35 (Exc VAT)		0
35	104030	Nyloc Nut M8 x 1.25 x 9.5	-	4	£0.20 (Exc VAT)		0
36	205005	RH Shock Absorber Connection	-	1	£114.87 (Exc VAT)	?	0
36	205006	LH Shock Absorber Connection	-	1	£114.87 (Exc VAT)	?	0
37	14312034	Screw No longer supplied- -Replaced by 212601	-	2	£39.10 (Exc VAT)	?	0
37	212601	Screw 14x1.5x45	-	2	£15.76 (Exc VAT)	?	0
38	11194174	Washer No longer supplied	-	2	£4.03 (Exc VAT)	?	0
39	178929	Ball Joint Only No longer supplied- -Replaced by 203633	-	2	£245.70 (Exc VAT)	?	0
39	203633	Upper Ball Joint	-	2	£154.72 (Exc VAT)	?	0
40	178928	Ball Joint Only No longer supplied- -Replaced by 203632	-	2	POA (Exc VAT)	?	0
	Superseded by 203632	Lower Ball Joint	N	2	£190.75 (Exc VAT)		0
40	203632	Lower Ball Joint	-	2	£190.75 (Exc VAT)		0
41	14496624	Washer D. 10.50-21 x2	-	8	£0.05 (Exc VAT)		0
42	14058621	Flanged Nut M10 x 1.25 x 11.8	-	8	£0.34 (Exc VAT)		0
