Ferrari / 308 GTB/GTS USA / 040 - Rear Suspension - Wishbones

Reset

< Prev Next >

001 - Engine - Gearbox And Supports

002 - Crankcase

003 - Crankshaft - Connecting Rods And Pistons

004 - Flywheel And Clutch Housing Spacer

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Air Pump And Pipings

010 - Guards

011 - Antievaporative Emission Control System

012 - Fuel Pump And Pipes

013 - Intake Air Cleaner Valve And Lines

014 - Carburettors And Air Cleaner

015 - Weber 40 DCNF 72/73/74/75 Carburettors

016 - Throttle Control

017 - Exhaust System

018 - Blow - By System

019 - Lubrication System

020 - Cooling System

021 - Water Pump And Pipings

022 - Clutch Operating Control

023 - Clutch Unit And Cover

024 - Gearbox Transmission

025 - Gearbox - Differential Housing And Oil Sump

026 - Main Shaft Gears

027 - Lay Shaft Gears

028 - Inside Gearbox Controls

029 - Outside Gearbox Controls

030 - Differential And Axle Shafts

031 - Pedal Board - Brake And Clutch Controls

032 - Brake System

033 - Calipers For Front And Rear Brakes

034 - Hand - Brake Control

035 - Steering Box And Linkage

036 - Steering Column

037 - Front Suspension - Shock Absorber And Brake Disc

038 - Front Suspension - Wishbones

039 - Rear Suspension - Shock Absorber And Brake Disc

040 - Rear Suspension - Wishbones

041 - Wheels

042 - Engine Ignition

043 - Electric Generating System

044 - Air Conditioning System

045 - Air Conditioning Compressor And Controls

046 - Toolkit

102 - Body Shell - Outer Elements

103 - Body Shell - Inner Elements

104 - Body Shell - Inner Elements

105 - Passenger And Luggage Compartments Insulation

106 - Front Compartment Lid

107 - Rear Bonnet And Luggage Compartment Covering

108 - Doors

109 - Bumpers And Moldings

110 - Glasses

111 - Interior Trim, Accessories And Seats

112 - Tunnel And Roof

113 - Instrument Panel

114 - Carpeting

115 - Instruments & Accessories

116 - Body Electrical

117 - Fuses And Relays

118 - Headlights Lifting Device

119 - Lights

120 - Windshield Wiper, Washer And Horn

121 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	104422	LH Upper Rear Suspension wishbone	-	1	£796.72 (Exc VAT)		0
1	104423	RH Upper Rear Suspension Lever	MP -	1	£1,601.63 (Exc VAT)		0
2	104428	RH Rear Lower Suspension Lever	-	1	£1,785.29 (Exc VAT)	?	0
2	104429	LH Lower Rear Suspension Lever	- £££	1	£1,040.97 (Exc VAT)	?	0
3	103170	Bush * In alternativa al n. 111616	-	8	POA (Exc VAT)	?	0
	Superseded by 154536	Silentbloc Bush	MP N	8	£44.56 (Exc VAT)		0
4	105340	Suspension Outer Bush	MP -	8	£40.47 (Exc VAT)		0
5	105341	Suspension Washer	MP -	8	£19.12 (Exc VAT)		0
6	105342	Large Suspension Seal	MP -	8	£18.81 (Exc VAT)		0
7	105343	Small Suspension Seal	MP -	8	£14.70 (Exc VAT)		0
8	100787	Suspension Inner Bush	MP -	8	£5.76 (Exc VAT)		0
9	101009	Suspension Thrust Washer	MP -	8	£7.26 (Exc VAT)		0
10	100796	Locating Pin	-	8	£3.47 (Exc VAT)		0
11	109905	Stainless Steel Bush	MP -	8	£41.08 (Exc VAT)		0
12	109902	Thrust Washer	MP -	8	£29.93 (Exc VAT)		0
13	104439	Suspension Fork	-	4	£159.80 (Exc VAT)		0
14	101041	Washer 14.5x24x2.5	-	4	£0.18 (Exc VAT)		0
15	12575821	Nut	-	4	POA (Exc VAT)	?	0
	Superseded by 150238	Nyloc Nut M14 x 1.5 x 14	N	4	£0.21 (Exc VAT)		0
16	101039	Shim Washer 1.00mm	MP -	14	£2.17 (Exc VAT)		0
16	107338	Shim Washer 1.50mm	MP -	14	£19.58 (Exc VAT)		0
16	107339	Shim Washer 2.00mm	MP -	14	£1.67 (Exc VAT)		0
16	107340	Shim Washer 2.50mm	MP -	14	£1.80 (Exc VAT)		0
16	107341	Shim Washer 3.00mm	MP -	14	£7.72 (Exc VAT)		0
16	107342	Shim Washer 3.25mm	-	14	£0.74 (Exc VAT)		0
17	106419	Suspension Bolt M12 x 1.25 x 71	-	8	£29.25 (Exc VAT)		0
18	16105121	Nyloc Nut	-	8	POA (Exc VAT)	?	0
	Superseded by 148020	Nut M12 x 1.25	N	8	£3.47 (Exc VAT)		0
19	105344	Bolt	MP -	4	£43.21 (Exc VAT)		0
20	16105121	Nyloc Nut	-	4	POA (Exc VAT)	?	0
21	108841	Anti Roll Bar Rear 15mm GTB * Solo per GTB	-	1	POA (Exc VAT)	?	0
21	112872	Anti Roll Bar Rear GTS * Solo per GTS	-	1	£401.72 (Exc VAT)		0
22	108748	Anti Roll Bar Bush GTS * Solo per GTS	MP -	2	£19.96 (Exc VAT)		0
22	109010	Anti Roll Bar Bush GTB * Solo per GTB	MP -	2	£20.67 (Exc VAT)		0
23	104417	Bracket - Anti Roll Bar	MP -	2	£39.77 (Exc VAT)		0
24	102742	Nyloc Nut M10x1.25x10	-	4	£0.32 (Exc VAT)		0
25	108432	Anti Roll Bar Link	MP -	2	£278.43 (Exc VAT)		0
26	100773	Bonded Silent Bloc Bush	MP -	2	£28.01 (Exc VAT)		0
27	108244	Rubber Bloc GTB	MP -	4	£12.40 (Exc VAT)		0
28	108294	Spacer	-	2	£69.68 (Exc VAT)	?	0
	Alternative 108294/A	Spacer	MP N	2	£48.72 (Exc VAT)		0
29	16104421	Nut GTB	-	2	POA (Exc VAT)	?	0
	Superseded by 101139	Nyloc Nut 8x1.25mm	N	2	£0.25 (Exc VAT)		0
30	107409	Washer	-	4	£1.88 (Exc VAT)		0
31	16105121	Nyloc Nut	-	2	POA (Exc VAT)	?	0
32	108913	Spacer	MP -	4	£12.27 (Exc VAT)		0
