Ferrari / 308 GTB/GTS USA / 017 - Exhaust System

Reset

< Prev Next >

001 - Engine - Gearbox And Supports

002 - Crankcase

003 - Crankshaft - Connecting Rods And Pistons

004 - Flywheel And Clutch Housing Spacer

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Air Pump And Pipings

010 - Guards

011 - Antievaporative Emission Control System

012 - Fuel Pump And Pipes

013 - Intake Air Cleaner Valve And Lines

014 - Carburettors And Air Cleaner

015 - Weber 40 DCNF 72/73/74/75 Carburettors

016 - Throttle Control

017 - Exhaust System

018 - Blow - By System

019 - Lubrication System

020 - Cooling System

021 - Water Pump And Pipings

022 - Clutch Operating Control

023 - Clutch Unit And Cover

024 - Gearbox Transmission

025 - Gearbox - Differential Housing And Oil Sump

026 - Main Shaft Gears

027 - Lay Shaft Gears

028 - Inside Gearbox Controls

029 - Outside Gearbox Controls

030 - Differential And Axle Shafts

031 - Pedal Board - Brake And Clutch Controls

032 - Brake System

033 - Calipers For Front And Rear Brakes

034 - Hand - Brake Control

035 - Steering Box And Linkage

036 - Steering Column

037 - Front Suspension - Shock Absorber And Brake Disc

038 - Front Suspension - Wishbones

039 - Rear Suspension - Shock Absorber And Brake Disc

040 - Rear Suspension - Wishbones

041 - Wheels

042 - Engine Ignition

043 - Electric Generating System

044 - Air Conditioning System

045 - Air Conditioning Compressor And Controls

046 - Toolkit

102 - Body Shell - Outer Elements

103 - Body Shell - Inner Elements

104 - Body Shell - Inner Elements

105 - Passenger And Luggage Compartments Insulation

106 - Front Compartment Lid

107 - Rear Bonnet And Luggage Compartment Covering

108 - Doors

109 - Bumpers And Moldings

110 - Glasses

111 - Interior Trim, Accessories And Seats

112 - Tunnel And Roof

113 - Instrument Panel

114 - Carpeting

115 - Instruments & Accessories

116 - Body Electrical

117 - Fuses And Relays

118 - Headlights Lifting Device

119 - Lights

120 - Windshield Wiper, Washer And Horn

121 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	111901	Main Silencer Part Number 111901: The above exhaust system is in compliance with the Exhaust System certification Regulation of: 1) California Administrative Code, Chapter 2, Title 13; and 2) Florida Administrative Code, Part III, Chapter 17Â·18	-	1	POA (Exc VAT)	?	0
2	111898	Exhaust Bracket	-	2	£44.79 (Exc VAT)		0
3	105938	Brass Nut	MP -	4	POA (Exc VAT)	?	0
	Superseded by 114748	Lock Nut M8 x 1.25 x 8	N	4	£12.21 (Exc VAT)		0
4	10519601	Washer 8.15-17 X 2	-	4	£0.05 (Exc VAT)	?	0
	Superseded by 10519624	Washer 8.15-17x2	N	4	£0.11 (Exc VAT)		0
5	106852	Spring Washer 8mm	-	4	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	4	£0.05 (Exc VAT)		0
6	106052	Exhaust Mount	-	2	£105.06 (Exc VAT)		0
7	108257	Fork	MP -	2	£100.31 (Exc VAT)		0
8	10033411	Pin	-	2	POA (Exc VAT)	?	0
	Superseded by 10033414	Clevis Pin	N	2	£8.63 (Exc VAT)		0
9	10796401	Split Pin	-	2	POA (Exc VAT)	?	0
10	103167	Washer	-	2	£2.95 (Exc VAT)		0
11	10977621	Bolt	-	8	POA (Exc VAT)	?	0
	Superseded by 10977624	Screw TE M5 x 12	N	8	£0.05 (Exc VAT)		0
12	15896411	RH Thread Nut	-	8	POA (Exc VAT)	?	0
	Superseded by 15896414	Nut	N	8	£0.06 (Exc VAT)		0
13	106849	Spring Washer	-	8	POA (Exc VAT)	?	0
	Superseded by 127493	Spring Washer 5mm	N	8	£0.07 (Exc VAT)		0
14	111583	Muffler Ver/Us/J	-	2	POA (Exc VAT)	?	0
15	112494	Bracket	-	2	£9.42 (Exc VAT)		0
16	16043221	Bolt M8 x 16	-	2	£0.09 (Exc VAT)		0
17	105938	Brass Nut	MP -	2	POA (Exc VAT)	?	0
18	111716	Heat Shield	-	1	POA (Exc VAT)	?	0
19	10902021	Bolt	-	4	POA (Exc VAT)	?	0
	Superseded by 10902024	Screw M6 x 12	N	4	£0.05 (Exc VAT)		0
20	12643701	Flat Washer	-	4	£0.05 (Exc VAT)		0
21	106850	Spring Washer 6mm	-	4	POA (Exc VAT)	?	0
	Superseded by 127494	Wavy Washer 6mm Zinc Coated	N	4	£0.07 (Exc VAT)		0
22	111697	Mon 8 82 Usa FrtmanifoldVer/Us/J	-	1	£720.40 (Exc VAT)	?	0
23	111698	308/Mondial 8 Rear Manifold Version USA/Japan	-	1	£1,295.13 (Exc VAT)		0
24	111699	Exhaust Tube Ver/Us/J	-	1	£725.22 (Exc VAT)		0
25	111700	Pipe Ver/Us/J	-	1	£321.06 (Exc VAT)		0
26	113111	Exhaust Ring Pkt 4	-	4	POA (Exc VAT)		0
27	111693	Gasket	-	2	POA (Exc VAT)	?	0
	Superseded by 147829	Exhaust Ring (58X46x17)	MP N	2	£27.90 (Exc VAT)		0
28	112982	Spring	-	1	£8.08 (Exc VAT)		0
29	112983	Plate	-	1	£3.31 (Exc VAT)		0
30	108258	Emmission Tube	-	1	POA (Exc VAT)	?	0
31	103748	Brass Bolt	-	8	£53.80 (Exc VAT)	?	0
32	103749	Gasket Washer	-	8	£0.20 (Exc VAT)		0
33	103587	Locktab	MP -	8	£6.39 (Exc VAT)		0
34	108260	Bracket	-	1	£5.44 (Exc VAT)		0
35	103549	Rubber Bush D. 9 x 2.5	-	1	£0.99 (Exc VAT)		0
36	103550	Metal Bush Insert	-	1	£4.68 (Exc VAT)	?	0
37	10902621	Bolt M6 x 25	-	1	£0.08 (Exc VAT)		0
38	12574211	Nyloc Nut M6x1	-	1	POA (Exc VAT)	?	0
	Superseded by 102948	Nyloc Nut M6 x 8	N	1	£0.19 (Exc VAT)		0
39	106744	Washer	-	1	£7.51 (Exc VAT)		0
40	108716	Plate Ver/Us/Aus/J	-	1	£139.14 (Exc VAT)		0
41	108717	Shield Ver/Us/J	-	1	£58.47 (Exc VAT)		0
42	10902321	Bolt	-	2	POA (Exc VAT)	?	0
	Superseded by 10902324	Screw M6 x 18	N	2	£0.12 (Exc VAT)		0
43	10902121	Bolt	MP -	1	POA (Exc VAT)	?	0
	Superseded by 10902124	Screw M6 x 14	N	1	£0.05 (Exc VAT)		0
44	15896211	Nut M6 x 5	-	3	£0.06 (Exc VAT)		0
45	106850	Spring Washer 6mm	-	3	POA (Exc VAT)	?	0
46	12643701	Flat Washer	-	5	£0.05 (Exc VAT)		0
47	113220	Manifold Tube	-	1	POA (Exc VAT)	?	0
48	113221	Manifold Tube	-	1	£57.66 (Exc VAT)		0
49	113222	Manifold Tube	-	1	£94.66 (Exc VAT)		0
50	113223	Manifold Tube	-	1	£62.91 (Exc VAT)		0
51	10977621	Bolt	-	2	POA (Exc VAT)	?	0
52	15896411	RH Thread Nut	-	2	POA (Exc VAT)	?	0
53	106849	Spring Washer	-	2	POA (Exc VAT)	?	0
54	111744	Stud	MP -	16	£26.30 (Exc VAT)	?	0
55	113108	Manifold Stud	-	2	£18.28 (Exc VAT)		0
56	111743	Exhaust Bracket Spring	-	18	£27.24 (Exc VAT)		0
57	113113	Washer 8mm hole	MP -	18	£4.35 (Exc VAT)	?	0
58	113112	Self Locking Nut	-	36	£1.86 (Exc VAT)		0
59	112761	Washer	-	35	£0.61 (Exc VAT)	?	0
60	106125	Gasket Exhaust	MP -	8	£10.51 (Exc VAT)		0
61	10519601	Washer 8.15-17 X 2	-	2	£0.05 (Exc VAT)	?	0
62	106852	Spring Washer 8mm	-	2	POA (Exc VAT)	?	0
63	111703	Exhaust Temp Probe	MP -	2	£229.74 (Exc VAT)		0
