033 - Front Suspension - Shock Absorber And Brake Discs

001 - Engine - Gearbox And Supports

002 - Crankcase

003 - Crankshaft - Connecting Rods And Pistons

004 - Flywheel And Clutch Housing Spacer

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Fuel System

010 - Carburettors And Air Cleaner

011 - Weber 40 DCNF Carbs (2 Distributors)

11A - Weber 40 DCNF Carbs (1 Distributor)

012 - Throttle Control (2 Distributors)

12A - Throttle Control (1 Distributor)

013 - Exhaust System

014 - Blow-By System

015 - Lubrication System

016 - Cooling System

017 - Water Pump And Pipings

018 - Clutch Operating Control

019 - Clutch Unit And Cover

020 - Gearbox Transmission

021 - Gearbox - Differential Housing And Oil Sump

022 - Main Shaft Gears

023 - Lay Shaft Gears

024 - Inside Gearbox Controls

025 - Outside Gearbox Controls (Up To No. 10114 Gs - 10100 Gd - 10358 U.S. Version)

25A - Outside Gearbox Controls (From No. 11324 Gs - 11300 Gd - 10360 U.S. Version)

026 - Differential And Axle Shaft (Up To Gearbox No. 692)

26A - Differential And Axle Shaft (From Gearbox No. 693)

027 - Pedal Board - Brake And Clutch Controls

028 - Brake System (Up To No. 11482 GS-12... GD-11462 USA)

28A - Brake System (From No. 11506 GS-12... GD-11994 USA)

029 - Calipers For Front And Rear Brakes

030 - Hand - Brake Control

031 - Steering Box And Linkage

032 - Steering Column

033 - Front Suspension - Shock Absorber And Brake Discs

034 - Front Suspension - Wishbones

035 - Rear Suspension - Shock Absorber And Brake Discs

036 - Rear Suspension - Wishbones

037 - Wheels

038 - Engine Ignition (2 Distributors)

38A - Engine Ignition (1 Distributor)

039 - Electric Generating System

040 - Air Conditioning System (Up To N. 12162)

40A - Air Conditioning System (From No. 12180)

041 - Air Conditioning Compressor And Controls

042 - Tool - Kit

043 - Throttle Control (R.H.D Version)

044 - Pedal Board - Clutch Control (R.H.D Version)

045 - Brake Hydraulic System (R.H.D Version)

046 - Front Air Pump And Pipings (U.S. 1976 Version)

047 - Rear Air Pump And Pipings (U.S. And Australian Versions 1976)

048 - Air Pump Guards (U.S. And Australian Versions 1976)

049 - Fast Idle Device (U.S. And Australian Versions 1976)

050 - Weber 40 DCNF Carburettors (U.S. 1976 Version)

50A - Weber 40 DCNF Carburettors (Australian 1976 Version)

051 - Fuel System (Up To No. 11462 - U.S. 1976 Version)

51A - Fuel System (From No.11994 - U.S. 1976 Version)

052 - Exhaust System (U.S. And Australian Versions 1976)

053 - Engine Ignition (U.S. And Australian Versions 1976)

054 - Water Radiator - Gear - Lever Housing (U.S. 1976 Version)

101 - Body Shell

102 - Body Shell - Outer Elements

103 - Body Shell - Inner Elements

104 - Body Shell - Inner Elements (U.S.Version)

105 - Body Shell - Inner Elements

106 - Front Compartment Lid

107 - Engine Compartment Lid And Carpeting

108 - Luggage Compartment Lid

109 - Doors

110 - Doors

111 - Bumpers And Mouldings

112 - Bumpers (U.S. Version)

112A - Bumpers (US Version)

113 - Glasses

114 - Interior Trim And Accessories

115 - Interior Trim And Accessories

116 - Seats

117 - Carpeting

118 - Instruments And Accessories

119 - Seat Belts

120 - Electrical System

121 - Fuses And Relays

122 - Headlights Lifting Device

123 - Lights

124 - Windshield Wiper, Washer And Horn

125 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	106260	Road Spring	-	2	POA (Exc VAT)	?	0
	Superseded by 113054	Front Road Spring	MP N	2	£372.25 (Exc VAT)		0
2	105223	Shock Absorber Dust Cover	MP -	2	£36.86 (Exc VAT)		0
3	103264	Lower Spring Pad	-	2	£29.17 (Exc VAT)		0
4	106261	Front Shock Absorber GTS	- £££	2	POA (Exc VAT)	?	0
	Superseded by 110786	Front Shock Absorber 308 GTB/GTS	N £££	2	£489.31 (Exc VAT)		0
5	104414	Bump Stop	-	2	POA (Exc VAT)	?	0
6	100809	Shock Absorber Mounting Bush	-	4	£16.70 (Exc VAT)		0
7	104374	RH Front Stub Axle	-	1	POA (Exc VAT)	?	0
	Superseded by 113820	RH Front Stub Axle	N	1	£727.70 (Exc VAT)		0
7	104375	LH Front Stub Axle	-	1	POA (Exc VAT)	?	0
8	14044171	RH Thread Nut Non Grooved Corner	MP -	1	£15.61 (Exc VAT)		0
8	14044871	LH Thread Hub Nut Grooved Corner	MP -	1	£16.13 (Exc VAT)		0
9	101446	Washer	MP -	2	£15.50 (Exc VAT)		0
10	104349	Front Wheel Hub	-	2	POA (Exc VAT)	?	0
11	105844	Bearing (Front Wheel)	-	2	£59.76 (Exc VAT)		0
12	105845	Tapered Roller Bearing (Front Wheel)	MP -	2	£14.15 (Exc VAT)		0
13	104359	Hub Seal Ring	MP -	2	£11.28 (Exc VAT)		0
14	104360	Front Hub Spacer	-	2	£6.26 (Exc VAT)		0
15	104361	Hub Cover	-	2	POA (Exc VAT)	?	0
	Superseded by 114095	Metal Dust Cap	N	2	£40.65 (Exc VAT)		0
16	104368	Location Peg	MP -	4	£12.96 (Exc VAT)		0
17	104596	RH Brake Disc Shield	-	1	POA (Exc VAT)	?	0
17	104597	LH Brake Disc Shield	-	1	POA (Exc VAT)	?	0
18	16043221	Bolt M8 x 16	-	2	£0.09 (Exc VAT)		0
19	10516671	Washer	-	2	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	2	£0.05 (Exc VAT)		0
20	106072	Front Brake Disc	MP -	2	£354.44 (Exc VAT)		0
