Ferrari / 308 GT4 Dino 1976 / 036 - Rear Suspension - Wishbones

Reset

< Prev Next >

001 - Engine - Gearbox And Supports

002 - Crankcase

003 - Crankshaft - Connecting Rods And Pistons

004 - Flywheel And Clutch Housing Spacer

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Fuel System

010 - Carburettors And Air Cleaner

011 - Weber 40 DCNF Carbs (2 Distributors)

11A - Weber 40 DCNF Carbs (1 Distributor)

012 - Throttle Control (2 Distributors)

12A - Throttle Control (1 Distributor)

013 - Exhaust System

014 - Blow-By System

015 - Lubrication System

016 - Cooling System

017 - Water Pump And Pipings

018 - Clutch Operating Control

019 - Clutch Unit And Cover

020 - Gearbox Transmission

021 - Gearbox - Differential Housing And Oil Sump

022 - Main Shaft Gears

023 - Lay Shaft Gears

024 - Inside Gearbox Controls

025 - Outside Gearbox Controls (Up To No. 10114 Gs - 10100 Gd - 10358 U.S. Version)

25A - Outside Gearbox Controls (From No. 11324 Gs - 11300 Gd - 10360 U.S. Version)

026 - Differential And Axle Shaft (Up To Gearbox No. 692)

26A - Differential And Axle Shaft (From Gearbox No. 693)

027 - Pedal Board - Brake And Clutch Controls

028 - Brake System (Up To No. 11482 GS-12... GD-11462 USA)

28A - Brake System (From No. 11506 GS-12... GD-11994 USA)

029 - Calipers For Front And Rear Brakes

030 - Hand - Brake Control

031 - Steering Box And Linkage

032 - Steering Column

033 - Front Suspension - Shock Absorber And Brake Discs

034 - Front Suspension - Wishbones

035 - Rear Suspension - Shock Absorber And Brake Discs

036 - Rear Suspension - Wishbones

037 - Wheels

038 - Engine Ignition (2 Distributors)

38A - Engine Ignition (1 Distributor)

039 - Electric Generating System

040 - Air Conditioning System (Up To N. 12162)

40A - Air Conditioning System (From No. 12180)

041 - Air Conditioning Compressor And Controls

042 - Tool - Kit

043 - Throttle Control (R.H.D Version)

044 - Pedal Board - Clutch Control (R.H.D Version)

045 - Brake Hydraulic System (R.H.D Version)

046 - Front Air Pump And Pipings (U.S. 1976 Version)

047 - Rear Air Pump And Pipings (U.S. And Australian Versions 1976)

048 - Air Pump Guards (U.S. And Australian Versions 1976)

049 - Fast Idle Device (U.S. And Australian Versions 1976)

050 - Weber 40 DCNF Carburettors (U.S. 1976 Version)

50A - Weber 40 DCNF Carburettors (Australian 1976 Version)

051 - Fuel System (Up To No. 11462 - U.S. 1976 Version)

51A - Fuel System (From No.11994 - U.S. 1976 Version)

052 - Exhaust System (U.S. And Australian Versions 1976)

053 - Engine Ignition (U.S. And Australian Versions 1976)

054 - Water Radiator - Gear - Lever Housing (U.S. 1976 Version)

101 - Body Shell

102 - Body Shell - Outer Elements

103 - Body Shell - Inner Elements

104 - Body Shell - Inner Elements (U.S.Version)

105 - Body Shell - Inner Elements

106 - Front Compartment Lid

107 - Engine Compartment Lid And Carpeting

108 - Luggage Compartment Lid

109 - Doors

110 - Doors

111 - Bumpers And Mouldings

112 - Bumpers (U.S. Version)

112A - Bumpers (US Version)

113 - Glasses

114 - Interior Trim And Accessories

115 - Interior Trim And Accessories

116 - Seats

117 - Carpeting

118 - Instruments And Accessories

119 - Seat Belts

120 - Electrical System

121 - Fuses And Relays

122 - Headlights Lifting Device

123 - Lights

124 - Windshield Wiper, Washer And Horn

125 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	104423	RH Upper Rear Suspension Lever	MP -	1	£1,601.63 (Exc VAT)		0
1	104422	LH Upper Rear Suspension wishbone	-	1	£796.72 (Exc VAT)		0
2	104428	RH Rear Lower Suspension Lever	-	1	£1,785.29 (Exc VAT)	?	0
2	104429	LH Lower Rear Suspension Lever	- £££	1	£1,040.97 (Exc VAT)	?	0
3	103170	Bush	-	8	POA (Exc VAT)	?	0
	Superseded by 154536	Silentbloc Bush	MP N	8	£44.56 (Exc VAT)		0
4	105340	Suspension Outer Bush	MP -	8	£40.47 (Exc VAT)		0
5	105341	Suspension Washer	MP -	8	£19.12 (Exc VAT)		0
6	105342	Large Suspension Seal	MP -	8	£18.81 (Exc VAT)		0
7	105343	Small Suspension Seal	MP -	8	£14.70 (Exc VAT)		0
8	100787	Suspension Inner Bush	MP -	8	£5.76 (Exc VAT)		0
9	101009	Suspension Thrust Washer	MP -	8	£7.26 (Exc VAT)		0
10	100796	Locating Pin	-	8	£3.47 (Exc VAT)		0
11	109905	Stainless Steel Bush	MP -	8	£41.08 (Exc VAT)	?	0
	Superseded by 600740	Stainless Steel Bush	MP N	8	£36.70 (Exc VAT)		0
12	109902	Thrust Washer	MP -	8	£29.93 (Exc VAT)	?	0
13	104439	Suspension Fork	-	4	£159.80 (Exc VAT)		0
14	101041	Washer 14.5x24x2.5	-	4	£0.18 (Exc VAT)		0
15	12575821	Nut	-	4	POA (Exc VAT)	?	0
	Superseded by 150238	Nyloc Nut M14 x 1.5 x 14	N	4	£0.21 (Exc VAT)		0
16	107340	Shim Washer 2.50mm	MP -	14	£1.80 (Exc VAT)		0
16	101039	Shim Washer 1.00mm	MP -	14	£2.17 (Exc VAT)		0
16	107338	Shim Washer 1.50mm	MP -	14	£19.58 (Exc VAT)		0
16	107339	Shim Washer 2.00mm	MP -	14	£1.67 (Exc VAT)		0
16	107341	Shim Washer 3.00mm	MP -	14	£7.72 (Exc VAT)		0
16	107342	Shim Washer 3.25mm	-	14	£0.74 (Exc VAT)		0
17	106419	Suspension Bolt M12 x 1.25 x 71	-	8	£29.25 (Exc VAT)		0
18	16105121	Nyloc Nut	-	8	POA (Exc VAT)	?	0
	Superseded by 148020	Nut M12 x 1.25	N	8	£3.47 (Exc VAT)		0
19	105344	Bolt	MP -	4	£43.21 (Exc VAT)		0
20	16105121	Nyloc Nut	-	4	POA (Exc VAT)	?	0
21	105057	Torsion Bar Upto N 08608	-	1	POA	?	0
22	106391	Rubber Bloc Upto N 08608	-	2	POA (Exc VAT)	?	0
	Superseded by 108747	Roll Bar Bush	MP N	2	£15.97 (Exc VAT)		0
22	108747	Roll Bar Bush On exhaustion N106391	MP -	2	£15.97 (Exc VAT)		0
23	104417	Bracket - Anti Roll Bar	MP -	2	£39.77 (Exc VAT)		0
24	12575621	Nyloc Nut	-	4	POA (Exc VAT)	?	0
	Superseded by 104114	Nyloc Nut M10 x 1.25 x 12	N	4	£0.30 (Exc VAT)		0
25	104420	Anti Roll Bar Link Upto N 08608	-	2	£686.70 (Exc VAT)	?	0
26	100773	Bonded Silent Bloc Bush	MP -	2	£28.01 (Exc VAT)		0
27	100984	Rubber Bush Upto N 08608	-	4	£8.32 (Exc VAT)		0
28	100985	Inner Bush Upto N 08608	MP -	2	£22.12 (Exc VAT)		0
29	105962	Bolt Upto N 08608	-	2	POA (Exc VAT)	?	0
30	16105121	Nyloc Nut Upto N 08608	-	2	POA (Exc VAT)	?	0
31	104421	Spacer	-	4	POA (Exc VAT)	?	0
	Superseded by 108913	Spacer	MP N	4	£12.27 (Exc VAT)		0
31	108913	Spacer On exhaustion N104421	MP -	2	£12.27 (Exc VAT)		0
32	12575721	Nut Upto N 09482	-	2	POA (Exc VAT)	?	0
32	16105121	Nyloc Nut From N 09484	-	2	POA (Exc VAT)	?	0
33	107334	Link Arm From N 08610	-	2	POA (Exc VAT)	?	0
	Superseded by 108432	Anti Roll Bar Link	MP N	2	£278.43 (Exc VAT)		0
33	108432	Anti Roll Bar Link On exhaustion N107334	MP -	2	£278.43 (Exc VAT)		0
34	107335	Rubber Bloc GTS From N 08610	MP -	4	£19.84 (Exc VAT)		0
34	108244	Rubber Bloc GTB On exhaustion N 107335	MP -	4	£12.40 (Exc VAT)		0
35	107336	Spacer	-	2	POA (Exc VAT)		0
35	108294	Spacer On exhaustion N107336	-	2	£69.68 (Exc VAT)	?	0
	Alternative 108294/A	Spacer	MP N	2	£48.72 (Exc VAT)		0
36	16104421	Nut GTB From N 08610	-	2	POA (Exc VAT)	?	0
	Superseded by 101139	Nyloc Nut 8x1.25mm	N	2	£0.25 (Exc VAT)		0
37	107409	Washer From N 08610	-	4	£1.88 (Exc VAT)		0
38	107415	Anti Roll Bar Rear 11mm From N 08610	-	1	POA (Exc VAT)	?	0
