Ferrari / 308 GT4 Dino 1976 / 013 - Exhaust System

Reset

< Prev Next >

001 - Engine - Gearbox And Supports

002 - Crankcase

003 - Crankshaft - Connecting Rods And Pistons

004 - Flywheel And Clutch Housing Spacer

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Fuel System

010 - Carburettors And Air Cleaner

011 - Weber 40 DCNF Carbs (2 Distributors)

11A - Weber 40 DCNF Carbs (1 Distributor)

012 - Throttle Control (2 Distributors)

12A - Throttle Control (1 Distributor)

013 - Exhaust System

014 - Blow-By System

015 - Lubrication System

016 - Cooling System

017 - Water Pump And Pipings

018 - Clutch Operating Control

019 - Clutch Unit And Cover

020 - Gearbox Transmission

021 - Gearbox - Differential Housing And Oil Sump

022 - Main Shaft Gears

023 - Lay Shaft Gears

024 - Inside Gearbox Controls

025 - Outside Gearbox Controls (Up To No. 10114 Gs - 10100 Gd - 10358 U.S. Version)

25A - Outside Gearbox Controls (From No. 11324 Gs - 11300 Gd - 10360 U.S. Version)

026 - Differential And Axle Shaft (Up To Gearbox No. 692)

26A - Differential And Axle Shaft (From Gearbox No. 693)

027 - Pedal Board - Brake And Clutch Controls

028 - Brake System (Up To No. 11482 GS-12... GD-11462 USA)

28A - Brake System (From No. 11506 GS-12... GD-11994 USA)

029 - Calipers For Front And Rear Brakes

030 - Hand - Brake Control

031 - Steering Box And Linkage

032 - Steering Column

033 - Front Suspension - Shock Absorber And Brake Discs

034 - Front Suspension - Wishbones

035 - Rear Suspension - Shock Absorber And Brake Discs

036 - Rear Suspension - Wishbones

037 - Wheels

038 - Engine Ignition (2 Distributors)

38A - Engine Ignition (1 Distributor)

039 - Electric Generating System

040 - Air Conditioning System (Up To N. 12162)

40A - Air Conditioning System (From No. 12180)

041 - Air Conditioning Compressor And Controls

042 - Tool - Kit

043 - Throttle Control (R.H.D Version)

044 - Pedal Board - Clutch Control (R.H.D Version)

045 - Brake Hydraulic System (R.H.D Version)

046 - Front Air Pump And Pipings (U.S. 1976 Version)

047 - Rear Air Pump And Pipings (U.S. And Australian Versions 1976)

048 - Air Pump Guards (U.S. And Australian Versions 1976)

049 - Fast Idle Device (U.S. And Australian Versions 1976)

050 - Weber 40 DCNF Carburettors (U.S. 1976 Version)

50A - Weber 40 DCNF Carburettors (Australian 1976 Version)

051 - Fuel System (Up To No. 11462 - U.S. 1976 Version)

51A - Fuel System (From No.11994 - U.S. 1976 Version)

052 - Exhaust System (U.S. And Australian Versions 1976)

053 - Engine Ignition (U.S. And Australian Versions 1976)

054 - Water Radiator - Gear - Lever Housing (U.S. 1976 Version)

101 - Body Shell

102 - Body Shell - Outer Elements

103 - Body Shell - Inner Elements

104 - Body Shell - Inner Elements (U.S.Version)

105 - Body Shell - Inner Elements

106 - Front Compartment Lid

107 - Engine Compartment Lid And Carpeting

108 - Luggage Compartment Lid

109 - Doors

110 - Doors

111 - Bumpers And Mouldings

112 - Bumpers (U.S. Version)

112A - Bumpers (US Version)

113 - Glasses

114 - Interior Trim And Accessories

115 - Interior Trim And Accessories

116 - Seats

117 - Carpeting

118 - Instruments And Accessories

119 - Seat Belts

120 - Electrical System

121 - Fuses And Relays

122 - Headlights Lifting Device

123 - Lights

124 - Windshield Wiper, Washer And Horn

125 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
-	106581	Mount	-	1	POA (Exc VAT)	?	0
1	106582	308Gt4 E M/Silencer W/Box	MP -	1	POA (Exc VAT)	?	0
2	106583	Front Exhaust Manifold	-	1	POA (Exc VAT)	?	0
2	108326	Front Exhaust Manifold On exhaustion N 106583	-	1	POA (Exc VAT)	?	0
3	106584	308GT4 - GTB/S Rear Manifold	-	1	POA (Exc VAT)	?	0
	Alternative 106584/S	Rear Manifold Stainless Steel	MP N	1	£1,354.23 (Exc VAT)		0
4	106052	Exhaust Mount	-	2	£110.32 (Exc VAT)		0
5	106674	Nut	-	2	£1.05 (Exc VAT)		0
6	12646801	Washer	-	4	£1.04 (Exc VAT)		0
7	10977621	Bolt	-	8	POA (Exc VAT)	?	0
	Superseded by 10977624	Screw TE M5 x 12	N	8	£0.05 (Exc VAT)		0
8	106849	Spring Washer	-	8	POA (Exc VAT)	?	0
	Superseded by 127493	Spring Washer 5mm	N	8	£0.08 (Exc VAT)		0
9	15896411	RH Thread Nut	-	8	POA (Exc VAT)	?	0
	Superseded by 15896414	Nut	N	8	£0.07 (Exc VAT)		0
10	106853	Spring Washer 10mm	-	2	POA (Exc VAT)	?	0
	Superseded by 12601474	Wavy Washer 10mm	N	2	£0.03 (Exc VAT)		0
11	106125	Gasket Exhaust	MP -	8	£11.04 (Exc VAT)		0
12	107358	Tube	-	1	£172.95 (Exc VAT)		0
13	103587	Locktab	MP -	4	£6.71 (Exc VAT)		0
14	103748	Brass Bolt	-	4	£56.49 (Exc VAT)	?	0
15	103749	Gasket Washer	-	4	£0.21 (Exc VAT)		0
16	107206	Heat Shield For N 106583	-	1	POA (Exc VAT)	?	0
16	108327	Heat Shield For N 108326	-	1	POA (Exc VAT)	?	0
17	107207	Exhaust Heat Shield	-	1	POA (Exc VAT)	?	0
18	107208	Shield	-	1	POA (Exc VAT)	?	0
	Superseded by 117252	Shield (heat)	MP N	1	£162.94 (Exc VAT)		0
19	103377	Exhaust Seal	-	2	POA (Exc VAT)		0
20	16044021	Bolt	-	6	POA (Exc VAT)	?	0
	Superseded by 16044024	Screw TE M8 x 40	N	6	£0.30 (Exc VAT)		0
21	106852	Spring Washer 8mm	-	6	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	6	£0.05 (Exc VAT)		0
22	105938	Brass Nut	MP -	6	POA (Exc VAT)	?	0
	Superseded by 114748	Lock Nut M8 x 1.25 x 8	N	6	£12.21 (Exc VAT)		0
23	10902121	Bolt	MP -	13	POA (Exc VAT)	?	0
24	106850	Spring Washer 6mm	-	13	POA (Exc VAT)	?	0
	Superseded by 127494	Wavy Washer 6mm Zinc Coated	N	13	£0.07 (Exc VAT)		0
25	12643701	Flat Washer	-	13	£0.05 (Exc VAT)		0
26	108188	Shield	-	1	POA (Exc VAT)	?	0
	Superseded by 118783	Shield	MP N	1	£148.38 (Exc VAT)		0
27	10902011	Screw 6x12	-	4	POA (Exc VAT)	?	0
	Superseded by 10902024	Screw M6 x 12	N	4	£0.05 (Exc VAT)		0
28	106744	Washer	-	4	£7.51 (Exc VAT)		0
29	10516471	Washer	-	4	POA (Exc VAT)	?	0
	Superseded by 127494	Wavy Washer 6mm Zinc Coated	N	4	£0.07 (Exc VAT)		0
30	103587	Locktab For N 106583	MP -	4	£6.71 (Exc VAT)		0
31	103748	Brass Bolt For N 106583	-	4	£56.49 (Exc VAT)	?	0
31	11903240	Exhaust Plug For N 108326	-	4	POA (Exc VAT)	?	0
	Superseded by 110860	Manifold Blanking Plug	N	4	£11.70 (Exc VAT)		0
32	103749	Gasket Washer For N 108326	-	4	£0.21 (Exc VAT)		0
32	10298460	Copper Washer For N 106583	-	4	£0.11 (Exc VAT)		0
