No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	50038405	RH Light Mask	-	1	POA (Exc VAT)	?	0
1	50038504	LH Light Mask	-	1	POA (Exc VAT)	?	0
2	50038108	RH Head Lamp Pop Up Housing	-	1	£564.96 (Exc VAT)		0
2	50038207	LH Head Lamp Pop Up Housing	MP -	1	£1,502.35 (Exc VAT)		0
3	50070507	Bush	MP -	4	£5.34 (Exc VAT)		0
4	50070606	Pin	MP -	4	£13.52 (Exc VAT)		0
5	50145903	RH Wiring Harness LHD Non vale per GD-D	-	1	POA (Exc VAT)	?	0
	Superseded by 50146000	LH Wiring Harness LHD	N	1	£73.77 (Exc VAT)		0
5	50179803	RH Wiring Harness RHD Vale per GD-D	-	1	£27.02 (Exc VAT)		0
5	50146000	LH Wiring Harness LHD Non vale per GD-D	-	1	£73.77 (Exc VAT)		0
5	50179902	LH Wiring Harness RHD Vale per GD-D	-	1	POA (Exc VAT)	?	0
6	50087709	Bump Stop	MP -	4	£9.84 (Exc VAT)		0
7	15896211	Nut M6 x 5	-	4	£0.06 (Exc VAT)		0
8	40089401	RH Head Lamp Motor	-	1	POA (Exc VAT)	?	0
8	40089500	LH Head Lamp Motor	-	1	POA (Exc VAT)	?	0
9	12605370	Washer	-	6	POA (Exc VAT)		0
10	10902111	Bolt	-	6	POA (Exc VAT)	?	0
	Superseded by 10902124	Screw M6 x 14	N	6	£0.05 (Exc VAT)		0
11	50085000	RH Head Lamp Bracket Non vale per D	-	1	£693.10 (Exc VAT)		0
11	50182708	RH Head Lamp Bracket Vale per D	-	1	£767.21 (Exc VAT)		0
11	50085109	LH Head Lamp Bracket Non vale per D	-	1	£693.10 (Exc VAT)		0
11	50182807	LH Head Lamp Bracket Vale per D	-	1	£767.21 (Exc VAT)		0
12	12608576	Washer	-	8	POA (Exc VAT)	?	0
13	50145804	Bolt	MP -	8	£15.01 (Exc VAT)		0
14	11087976	Circlip	-	4	POA (Exc VAT)	?	0
	Superseded by 11087974	Circlip	N	4	£0.15 (Exc VAT)		0
15	50038009	Lever	-	2	POA (Exc VAT)	?	0
	Alternative 61268600/A	Head Lamp Connecting Rod	N	2	£82.07 (Exc VAT)		0
16	30152805	Pin	-	2	POA (Exc VAT)	?	0
	Superseded by 40153009	Pin	N	2	£46.27 (Exc VAT)		0
17	10615770	Washer	-	2	POA (Exc VAT)	?	0
	Superseded by 10615774	Washer	N	2	£0.13 (Exc VAT)		0
18	12164711	Nut M10 x 1.25 x 8	-	2	£0.20 (Exc VAT)	?	0
	Alternative 133988	Plain Nut M10 x 1.25 x 8	N	2	£0.16 (Exc VAT)		0
19	30152508	Pivot	-	2	POA (Exc VAT)	?	0
	Superseded by 40213902	Pivot	N	2	£25.91 (Exc VAT)		0
20	50146109	Nut	-	2	£0.76 (Exc VAT)		0
21	30152607	Washer	-	2	POA (Exc VAT)	?	0
	Superseded by 40344806	Shims	N	2	£1.05 (Exc VAT)		0
22	50184902	Micro Switch Ver/D Vale per D	-	2	£69.43 (Exc VAT)		0
