Ferrari / 512 BB (Carburetor) / 031 - Front Suspension - Hub And Shock Absorber

Reset

< Prev Next >

031 - Front Suspension - Hub And Shock Absorber

001 - Crankcase

002 - Crankshaft, Connecting Rods And Pistons

003 - Cylinder Head (Right)

004 - Cylinder Head (Left)

004A - Cylinder Head (Left) (1978 Revision)

005 - Camshaft Drive System (Belts)

005A - Timing System - Controls (1978 Revision)

006 - Fuel Pumps And Fuel Pipes

007 - Fuel Tanks And Pipes

008 - Air Intakes, Filters And Manifolds

009 - Weber 40 If 3C/9/10/11/12 Carburettors

010 - Throttle Control

011 - Exhaust System

012 - Lubrication - Blow-By And Oil Reservoir

013 - Lubrication - Oil Pumps And Filters

014 - Cooling System

014A - Cooling System (1978 Revision)

015 - Water Pump And Pipes

016 - Clutch And Controls

016A - Clutch And Controls (1978 Revision)

017 - Clutch Release Control

018 - Transmission Drop Gears

019 - Gear Box - Mountings And Covers

020 - Gear Box

021 - Main Shaft Gears

022 - Lay Shaft Gears

023 - Gear Box Controls

024 - Differential And Axle Shafts

025 - Brake Hydraulic System

026 - Brake System

027 - Brake Calipers For Front And Rear

028 - Hand-Brake Control

029 - Steering Rack And Linkage

030 - Steering Column

031 - Front Suspension - Hub And Shock Absorber

032 - Front Suspension - Wishbones

033 - Rear Suspension Hub And Brake Disc

034 - Rear Suspension - Wishbones And Shock Absorbers

035 - Wheels

036 - Engine Ignition

037 - Alternator, Starter And Battery

038 - Air Conditioning System

039 - Tool Kit

040 - Throttle Control (For RHD Version)

041 - Clutch Release Control (For RHD Version)

042 - Brake Hydraulic System (For RHD Version)

101 - Body Mouldings, Badges And Grill

102 - Body Shell - Outer Elements

103 - Body Shell - Inner Elements Lower

104 - Body Shell - Inner Elements Upper

105 - Insulating Material And Bulkheads

106 - Front Compartment Lid

107 - Rear Bonnet

108 - Doors

109 - Fixed Glass

110 - Interior Trim, Accessories And Seats

111 - Tunnel And Roof

112 - Instrument Panel

113 - Carpeting

114 - Instruments And Accessories

115 - Electrical System

116 - Fuses And Relays

117 - Headlight Lifting Device

118 - Lights

119 - Windshield Wipers, Washer And Horns

120 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	110917	Front Road Spring	MP -	2	£388.02 (Exc VAT)		0
2	105223	Shock Absorber Dust Cover	MP -	2	£36.86 (Exc VAT)		0
3	103264	Lower Spring Pad	-	2	£29.17 (Exc VAT)		0
4	103265	N Front Shock Absorber	MP - £££	2	£318.35 (Exc VAT)		0
5	100809	Shock Absorber Mounting Bush	-	4	£16.70 (Exc VAT)		0
6	105311	Bump Stop	MP -	2	POA (Exc VAT)	?	0
	Alternative 139448	Rubber Pad	N	2	£24.10 (Exc VAT)		0
7	106419	Suspension Bolt M12 x 1.25 x 71	-	2	£29.25 (Exc VAT)		0
8	16105121	Nyloc Nut	-	2	POA (Exc VAT)	?	0
	Superseded by 148020	Nut M12 x 1.25	N	2	£3.47 (Exc VAT)		0
9	104589	RH Front Stub Axle	-	1	£815.77 (Exc VAT)		0
9	104590	LH Front Stub Axle	-	1	£815.77 (Exc VAT)		0
10	103241	Suspension Bolt	MP -	2	£54.38 (Exc VAT)		0
11	16105121	Nyloc Nut	-	2	POA (Exc VAT)	?	0
12	10724621	RH Thread Castellated Nut	-	1	POA (Exc VAT)	?	0
	Alternative 92429	RH Thread Castellated Nut	MP N	1	£37.74 (Exc VAT)		0
12	11638021	LH Thread Castellated Nut	-	1	POA (Exc VAT)	?	0
	Alternative 92431	LH Thread Castellated Nut	MP N	1	£27.46 (Exc VAT)		0
13	10733801	Split pin	-	2	POA (Exc VAT)	?	0
14	101446	Washer	MP -	2	£15.50 (Exc VAT)		0
15	101217	Ring Unmod Mod	-	2	POA (Exc VAT)	?	0
	Superseded by 110150	Ring (Oil Seal Cover)	MP N	2	£96.04 (Exc VAT)		0
16	101363	Tapered Roller Bearing	MP -	2	£23.48 (Exc VAT)		0
17	101219	Oil Seal	MP -	2	£14.04 (Exc VAT)		0
18	104588	Tapered Bearing	MP -	2	£38.52 (Exc VAT)		0
19	104594	RH Front Hub	-	1	£724.45 (Exc VAT)		0
19	104593	LH Front Hub	-	1	POA (Exc VAT)	?	0
20	103208	Front Brake Disc 365/512Bb*Fit in pairs	MP -	2	£520.36 (Exc VAT)		0
21	110901	RH Front Brake Disc Cover	-	1	POA (Exc VAT)	?	0
21	110902	LH Front Brake Disc Cover	-	1	POA (Exc VAT)	?	0
22	16043821	Bolt 8 x 30 UNI 5737	-	16	POA (Exc VAT)	?	0
	Superseded by 16043824	Bolt M8 x 30	N	16	£0.38 (Exc VAT)		0
23	16100821	Plain Nut 8mm x 6.25mm Pitch 1.25	-	16	POA (Exc VAT)	?	0
	Superseded by 16102314	Nut M8 x 5	N	16	£0.06 (Exc VAT)		0
24	10516671	Washer	-	16	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	16	£0.05 (Exc VAT)		0
25	16043221	Bolt M8 x 16	-	2	£0.09 (Exc VAT)		0
26	10516671	Washer	-	2	POA (Exc VAT)	?	0
27	106616	Washer	-	2	£1.08 (Exc VAT)	?	0
	Superseded by 12601574	Wavy Washer 13mm	N	2	£0.06 (Exc VAT)		0
28	12601571	Washer	-	4	POA (Exc VAT)	?	0
	Superseded by 12646724	Washer 8.45-20x2	N	4	£0.09 (Exc VAT)		0

Make an Enquiry Report an Issue

Part Availability Key

In Stock

In Stock - Supersession (Supersession price shown)

In Stock - Alternative (Alternative price shown)

In Stock - Partial Stock

Enquire
