Ferrari / 365 GT 2+2 MK2 from 12811 / 025 - Transmission Shaft

Reset

< Prev Next >

025 - Transmission Shaft

003 - Crankshaft, Connecting Rods And Pistons

004 - Cylinder Head (Right)

005 - Cylinder Head (Left)

006 - Weber 40 Df1/5 Carburettor

007 - Air Inlet With Blow-By

008 - Feeding And Controls

009 - Throttle Pedal

010 - Exhaust Pipes Assembly

011 - Timing (Controls)

012 - Timing (Accessories)

013 - Hydraulic Steering Pump And Controls

014 - Oil Pump And Filters

015 - Oil Pressure Valve

016 - Distributors & Controls

017 - Generator Accumulator Coils & Starter

018 - Clutch & Controls

020 - Lay Shaft

021 - Output Shaft

022 - Countershaft

023 - Gear Box Controls

024 - Rear Gear Box Housing

025 - Transmission Shaft

026 - Differential - Pinion And Crown

027 - Rear Axle & Axle

028 - Rear Suspension

029 - Rear Suspension - Damper And Self-Levelling Unit

030 - Front Wheel Suspension - Upper Arms

031 - Front Wheel Suspension - Bottom Arms

032 - Pedal Board - Clutch Control

033 - Pedal Board - Brake Control

034 - Brake System Scheme

035 - Front Brake Disc And Master-Cylinder

036 - Front & Rear Brakes Calipers

037 - Hand-Brake Control

038 - Rear Brake Disc And Wheel

039 - Steering Column

040 - Steering Linkage

041 - Radiator & Water Pump

042 - Fuel Tanks

043 - Air Conditioning

044 - Air Conditioning Layout Scheme

046 - Exhaust Pipes Assembly With Emissions Contol

047 - Ignition System With Emissions Control

048 - Air Pump With Emissions Control

049 - Generator With Emissions Control

050 - Idle Speed Control With Emissions Control

051 - Cooling System With Emissions Control

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price	Req.	Sel.
Multiple variants of the same part are selected for items:
1	560461	Coupling	-	2	POA (Exc VAT)			?	0
	Superseded by 104141	Sleeve	N	2	£177.22 (Exc VAT)				0
2	560466	Prop Shaft	-	1	£631.37 (Exc VAT)				0
3	560471	Tie Rod	-	1	£111.71 (Exc VAT)				0
4	520641	Rubber	-	2	POA (Exc VAT)			?	0
	Superseded by 100734	Bush	MP N	2	£41.97 (Exc VAT)				0
5	520938	Cup	-	2	POA (Exc VAT)			?	0
6	560474	Ring	-	4	£6.44 (Exc VAT)				0
7	560480	Spacer	-	1	£20.93 (Exc VAT)				0
8	560496	Pair of Bushes (Driveline)	-	1	£82.14 (Exc VAT)				0
9	560498	Drive Line Tube	-	1	£768.86 (Exc VAT)				0
10	560499	Drive Line Tube	-	1	£768.86 (Exc VAT)				0
11	94781	Washer	-	2	POA (Exc VAT)			?	0
	Alternative 104456	Washer	MP N	2	£14.94 (Exc VAT)				0
12	95900704	Nut	MP -	4	£11.65 (Exc VAT)				0
13	104145	Sealed Ball Bearing	-	1	POA (Exc VAT)			?	0
14	11060676	Circlip	-	1	POA (Exc VAT)			?	0
15	8X35	Bullone per manicotto	-	8	POA				0
16	127496	Spring Washer 8mm	-	8	£0.05 (Exc VAT)				0
17	95870011	Circlip AA30e	-	1	£0.75 (Exc VAT)				0
18	12x-40	Bullone fissaggio flange	-	4	POA				0
19	12x1,25M	Dado	-	4	POA				0
20	12x65	Bullone per tirante	-	1	POA				0
21	10520020	Washer	-	1	POA (Exc VAT)			?	0
22	95900614	Nut N70 112Ma	-	1	POA (Exc VAT)			?	0
