102 - Structures And Elements, Front Of Vehicle

000 - Spare Assembly Units

001 - Crankcase

002 - Crankshaft - Connecting Rods And Pistons

003 - Right Hand Cylinder Head

004 - Left Hand Cylinder Head

005 - Timing System - Tappets

006 - Timing System - Drive

007 - Injection - Ignition System

008 - Secondary Air System

009 - Fuel System Pumps And Pipes

010 - Fuel Tank And Filler Neck

011 - Evaporative Emissions Control System

012 - Intake Manifold

013 - Air Intake

014 - Pre-Catalytic Converters And Catalytic Converters

015 - Silencers

016 - Gearbox Oil Lubrication And Cooling System

017 - Lubrication System: Tank

018 - Cooling - Water / Oil Pump

019 - Cooling - Header Tank And Pipes

020 - Cooling - Radiators And Air Ducts

021 - Transmission Housing

022 - Transmission Pipe

023 - Complete Pedal Board Assembly

024 - Gearbox Housing

025 - Ptu System

026 - Ptu Repair Kit

027 - Servo Brake System

028 - Brake System

029 - Front Brake Callipers

030 - Rear Brake Callipers

031 - Parking Brake Control

032 - Hydraulic Power Steering Box

033 - Steering Control

034 - Power Steering Pump And Reservoir

035 - Front Suspension - Shock Absorber And Brake Disc

036 - Front Suspension - Arms

037 - Rear Suspension - Shock Absorber And Brake Disc

038 - Rear Suspension - Arms

039 - Wheels

040 - Vehicle Lift System

041 - Battery

042 - Alternator - Starter Motor

043 - Ac System Compressor

044 - Ac System - Water And Freon

045 - Evaporator Unit

046 - Dashboard Air Ducts

047 - Tools And Accessories Provided With Vehicle

048 - MAINTENANCE PROCEDURES -Applicable for S.T. Schedule only-

100 - Bodyshell - External Trim

101 - Greenhouse

102 - Structures And Elements, Front Of Vehicle

103 - Structures And Elements, Centre Of Vehicle

104 - Structures And Elements, Rear Of Vehicle

105 - Chassis Completion

106 - Flat Undertray And Wheelhouses

107 - Insulation

108 - Passenger Compartment Mats

109 - Luggage Compartment Mats

110 - Headliner Trim And Accessories

111 - Front Lid And Opening Mechanism

112 - Rear Lid And Opening Mechanism

113 - Fuel Filler Flap And Controls

114 - Doors - Substructure And Trim

115 - Doors - Opening Mechanisms And Hinges

116 - Doors - Power Window And Rear View Mirror

117 - Front Bumper

118 - Rear Bumper

119 - Screens, Windows And Seals

120 - Front Seat - Seat Belts, Guides And Adjustment

121 - Front Seat - Trim And Accessories

122 - Rear Seat - Seat Belts - Interior Trim

123 - Tunnel - Substructure And Accessories

124 - Dashboard - Substructure

125 - Dashboard - Trim

126 - Glove Compartment

127 - Airbags

128 - Dashboard And Tunnel Instruments

129 - Headlights And Taillights

130 - Shields - External Trim

131 - Windscreen Wiper, Windscreen Washer And Horns

132 - Main Wiring Harnesses

133 - Various Fastenings For The Electrical System

134 - Electronic Management (Suspension)

135 - VEHICLE ECUs

136 - Antitheft System

137 - Infotainment System

138 - Audio Speaker System

139 - Adhesive Labels And Plaques

140 - PAINTING -Applicable for S.T. Schedule only-

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	985265529	Engine Subframe	-	1	£8,677.92 (Exc VAT)	?	0
2	279287	RH Front Lower	-	1	POA (Exc VAT)	?	0
3	279288	LH Front Lower	-	1	POA (Exc VAT)	?	0
4	265605	RH Internal Engine Compartment Diagonal Brace	-	1	£355.01 (Exc VAT)	?	0
5	265606	LH Internal Engine Compartment Diagonal Brace LHD Not for GD	-	1	£355.01 (Exc VAT)	?	0
5	279231	LH Internal Engine Compartment Diagonal Brace RHD Applicable for GD	-	1	£138.03 (Exc VAT)	?	0
6	322551	Removable Strut Tower Connec	-	1	POA (Exc VAT)	?	0
7	288519	RH Outer Firewall Endpiece	-	1	POA (Exc VAT)	?	0
8	288520	LH Outer Firewall Endpiece	-	1	POA (Exc VAT)	?	0
9	284526	RH Pillar Endpiece	-	1	£8.05 (Exc VAT)	?	0
10	284525	LH Pillar Endpiece	-	1	£8.05 (Exc VAT)	?	0
11	265295	RH Upper External Diagonal Firewall Brace LHD Not for GD	-	1	£244.57 (Exc VAT)	?	0
11	277103	RH Upper External Diagonal Firewall Brace RHD Applicable for GD	-	1	£82.82 (Exc VAT)	?	0
12	265294	LH Upper External Diagonal Firewall Brace LHD Not for GD	-	1	£96.50 (Exc VAT)	?	0
12	277102	LH Upper External Diagonal Firewall Brace RHD Applicable for GD	-	1	£166.04 (Exc VAT)	?	0
13	270672	Connection Between Pillar And RH Lower Front	-	1	POA (Exc VAT)	?	0
14	270670	Connection Between Pillar And LH Lower Front	-	1	POA (Exc VAT)	?	0
15	332021	RH Front Brake Bracket	-	1	£24.47 (Exc VAT)	?	0
16	332019	LH Front Brake Bracket	-	1	£24.47 (Exc VAT)	?	0
17	278252	RH Front Suspension Mount Casting LHD Not for GD	-	1	POA (Exc VAT)	?	0
17	280742	RH Front Suspension Mount Casting RHD Applicable for GD	-	1	POA (Exc VAT)	?	0
18	278251	LH Front Suspension Mount Casting LHD Not for GD	-	1	POA (Exc VAT)	?	0
18	280741	LH Front Suspension Mount Casting RHD Applicable for GD	-	1	POA (Exc VAT)	?	0
19	266037	Front Subframe Cross Member	-	1	£591.68 (Exc VAT)	?	0
20	265539	RH Front Diagonal Subframe Brace	-	1	£157.78 (Exc VAT)	?	0
21	265540	LH Front Diagonal Subframe Brace	-	1	£157.78 (Exc VAT)	?	0
22	265557	RH Lower Extrusion LHD Not for GD	-	1	£148.08 (Exc VAT)	?	0
22	278213	RH Lower Extrusion RHD Applicable for GD	-	1	POA (Exc VAT)	?	0
23	265558	LH Lower Extrusion LHD Not for GD	-	1	£148.08 (Exc VAT)	?	0
23	279130	LH Lower Extrusion RHD Applicable for GD	-	1	£153.80 (Exc VAT)	?	0
24	265517	RH Central External Diagonal Firewall Brace LHD Request ASM authorisation- -Not for GD	-	1	£163.93 (Exc VAT)	?	0
24	276469	RH Central External Diagonal Firewall Brace RHD Request ASM authorisation- -Applicable for GD	-	1	£99.54 (Exc VAT)	?	0
25	265306	LH Central External Diagonal Firewall Brace LHD Request ASM authorisation- -Not for GD	-	1	£132.77 (Exc VAT)	?	0
25	274946	LH Central External Diagonal Firewall Brace RHD Request ASM authorisation- -Applicable for GD	-	1	£161.07 (Exc VAT)	?	0
26	265519	RH Lower Diagonal Firewall Brace	-	1	£210.16 (Exc VAT)	?	0
27	265521	LH Lower Diagonal Firewall Brace LHD	-	1	£210.16 (Exc VAT)	?	0
28	279223	RH Central Internal Diagonal Firewall Brace LHD Not for GD	-	1	POA (Exc VAT)	?	0
28	279222	RH Central Internal Diagonal Firewall Brace RHD Applicable for GD	-	1	£177.05 (Exc VAT)	?	0
29	279220	LH Central Internal Diagonal Firewall Brace LHD Not for GD	-	1	£118.56 (Exc VAT)	?	0
29	279224	LH Central Internal Diagonal Firewall Brace RHD Applicable for GD	-	1	£43.47 (Exc VAT)	?	0
30	323614	RH Front Crash Box Cross Mem Request ASM authorisation- -Not for GD	-	1	POA (Exc VAT)	?	0
30	328918	RH Front Crash Box Cross Mem Request ASM authorisation- -Applicable for GD- -Applicable up to Ass. No. 143958	-	1	POA (Exc VAT)	?	0
30	323614	RH Front Crash Box Cross Mem Request ASM authorisation- -Applicable for GD- -Applicable from Ass. No. 143959	-	1	POA (Exc VAT)	?	0
31	323612	LH Front Crash Box Cross Mem Request ASM authorisation- -Not for GD	-	1	POA (Exc VAT)	?	0
31	329101	LH Front Crash Box Cross Mem Request ASM authorisation- -Applicable for GD- -Applicable up to Ass. No. 143958	-	1	POA (Exc VAT)	?	0
31	323612	LH Front Crash Box Cross Mem Request ASM authorisation- -Applicable for GD- -Applicable from Ass. No. 143959	-	1	POA (Exc VAT)	?	0
32	323519	RH Lower Front Strut Request ASM authorisation- -Not for GD	-	1	POA (Exc VAT)	?	0
32	328912	RH Lower Front Strut Request ASM authorisation- -Applicable for GD- -Applicable up to Ass. No. 143958	-	1	POA (Exc VAT)	?	0
32	323519	RH Lower Front Strut Request ASM authorisation- -Applicable for GD- -Applicable from Ass. No. 143959	-	1	POA (Exc VAT)	?	0
33	323514	LH Lower Front Strut Request ASM authorisation- -Not for GD	-	1	POA (Exc VAT)	?	0
33	328915	LH Lower Front Strut Request ASM authorisation- -Applicable for GD- -Applicable up to Ass. No. 143958	-	1	POA (Exc VAT)	?	0
33	323514	LH Lower Front Strut Request ASM authorisation- -Applicable for GD- -Applicable from Ass. No. 143959	-	1	POA (Exc VAT)	?	0
34	265531	RH Upper Front Strut LHD Request ASM authorisation- -Not for GD	-	1	POA (Exc VAT)	?	0
34	277101	RH Upper Front Strut RHD Request ASM authorisation- -Applicable for GD	-	1	£56.03 (Exc VAT)	?	0
35	265534	LH Upper Front Strut LHD Request ASM authorisation- -Not for GD	-	1	POA (Exc VAT)	?	0
35	277100	LH Upper Front Strut RHD Request ASM authorisation- -Applicable for GD	-	1	£56.03 (Exc VAT)	?	0
36	88079200	Complete Front Bumper Cross Member	-	1	POA (Exc VAT)	?	0
37	14814434	Screw M8 x 25	-	4	£0.39 (Exc VAT)		0
38	12646724	Washer 8.45-20x2	-	4	£0.09 (Exc VAT)		0
39	86866700	Lower Front Cross-Member Request ASM authorisation	-	1	POA (Exc VAT)	?	0
40	87196000	Shelf Cross Member - Front Bumper	-	1	POA (Exc VAT)	?	0
41	83839000	Engine Compartment Lid Hinge Mounting Bracket	-	1	£60.04 (Exc VAT)	?	0
42	82439800	Front Bracket	-	2	£138.60 (Exc VAT)	?	0
43	277322	Screw 12x50	-	10	£2.21 (Exc VAT)		0
44	271283	Screw 10x70	-	2	£5.04 (Exc VAT)	?	0
45	277723	Screw 10x55	-	2	£5.04 (Exc VAT)	?	0
46	16043634	Screw M8 x 25	-	2	£0.17 (Exc VAT)		0
46	16044434	Screw	-	2	£1.45 (Exc VAT)		0
47	11194074	Washer 8.6-16x1.9	-	4	£0.04 (Exc VAT)		0
48	12646724	Washer 8.45-20x2	-	4	£0.09 (Exc VAT)		0
49	16043634	Screw M8 x 25	-	2	£0.17 (Exc VAT)		0
49	16044434	Screw	-	2	£1.45 (Exc VAT)		0
50	11194074	Washer 8.6-16x1.9	-	4	£0.04 (Exc VAT)		0
51	12646724	Washer 8.45-20x2	-	4	£0.09 (Exc VAT)		0
