Ferrari / F355 B/GTS/Spider Mo. 2.7 / 029 - Main Shaft Gears

Reset

< Prev Next >

001 - Crankcase

002 - Driving Shaft - Connecting Rods And Pistons

003 - R.H. Cylinder Head

004 - L.H. Cylinder Head

005 - Timing - Tappets And Shields

006 - Timing - Controls

007 - Injection Device - Ignition

008 - Air Injection Device

009 - Fuel Pump And Pipes -Valid For Cars With Double Fuel Pump-

010 - Fuel Pump And Pipes -Valid For Cars With Single Fuel Pump-

011 - Fuel Tank

012 - Antievaporation Device

013 - Air Boxes

014 - Air Intake

015 - Throttle Holders And Controls

016 - Accelerator Pedal

017 - Exhaust System

018 - Lubrication System

019 - Blow-By System

020 - Pumps And Oil Sump

021 - Cooling System - Nourice

022 - Cooling System Radiators

023 - Water Pump And Oil/Water Heat Exchanger

024 - Clutch And Controls

025 - Clutch Release Control -Not For Gd-

026 - Clutch Release Control -Valid For Gd-

027 - Gearbox - Differential Housing And Intermediate Casing

028 - Gearbox Covers And Lubrication

029 - Main Shaft Gears

030 - Lay Shaft Gears

031 - Inside Gearbox Controls

032 - Outside Gearbox Controls

033 - Differential And Axle Shafts

034 - Brake Hydraulic System

035 - Hydraulic System For Abs

036 - Brake System

037 - Calipers For Front And Rear Brakes

038 - Hand-Brake Control

039 - Hydraulic Steering Box -Valid For Steering Box With Power Steering Cars-

040 - Mechanical Steering Box -Valid For Mechanical Steering Box Cars-

041 - Steering Column

042 - Hydraulic Steering Pump -Valid For Steering Box With Power Steering Cars-

043 - Front Suspension - Shock Absorber And Brake Disc

044 - Front Suspension - Wishbones

045 - Rear Suspension - Shock Absorber And Brake Disc

046 - Rear Suspension - Wishbones

047 - Wheels

048 - Current Generator - Starting Motor - Battery

049 - Air Conditioning Compressor

050 - Tools Equipment

051 - Spare Wheel And Equipment - Optional-

100 - Body - General Units

101 - Body - Units

102 - Front Part Structures

103 - Central Part Structures

104 - Frame - Rear Part Elements

105 - Roof - Outer Trims

106 - Body - Outer Trims

107 - Body - Shields And Wheelhouses

108 - Passengers Compartment Insulations -Not For Spider-

109 - Passengers Compartment Insulations -Valid For Spider-

110 - Passengers Compartment Carpets -Not For Spider-

111 - Passengers Compartment Carpets -Valid For Spider-

112 - Front Compartment Carpets

113 - Roof Trims -Valid For Berlinetta-

114 - Roof Trims -Valid For Gts And Spider-

115 - Top -Valid For Spider-

116 - Top Hydraulic Control -Valid For Spider-

117 - Front Hood

118 - Opening Device For Front Hood

119 - Rear Hood

120 - Opening Devices For Rear Hood And Gas Door

121 - Doors - Framework And Rear Mirror

122 - Doors - Opening Control And Hinges

123 - Doors - Glass Lifting Device

124 - Doors - Inner Trims

125 - Front Bumper

126 - Rear Bumper

127 - Glasses And Gaskets

128 - Seats And Safety Belts -Comfort-Not For Spider-

129 - Seats And Safety Belts -Sport-Not For Spider-

130 - Seats And Safety Belts -Valid For Spider-

131 - Tunnel - Framework And Accessories

132 - Dashboard -Not For Air-Bag Cars-

133 - Dashboard -Valid For Air-Bag Cars-

134 - Air-Bag

135 - Instruments

136 - Front And Rear Lights

137 - Lights Lifting Device And Headlights

138 - Windshield Wiper And Controls

139 - Glass Washer And Horns

140 - Electrical System

141 - Electrical Boards - Passengers Compartment

142 - Electrical Boards And Devices - Front Part

143 - Evaporator Unit And Passengers Compartment Aeration

144 - Air Conditioning System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
-	70000838	Pinion Set 6th Gear Complete Valid for CH	-	1	£1,242.19 (Exc VAT)	?	0
-	70000828	Pinion Set 1st and 2nd Gear Complete	-	1	£3,647.76 (Exc VAT)	?	0
-	70000846	Pinion Set Neutral and Reverse Gear Complete Valid from gearbox Nr. 349- -Valid for pin 160937 - See Table 27 Pos. 2	-	1	POA (Exc VAT)	?	0
-	70000829	Pinion Set Neutral and Reverse Gear Complete Valid till gearbox Nr. 348- -Valid for pin 153992 - See Table 27 Pos. 2- -Not as spare part now - Replaced by 70000846	-	1	POA (Exc VAT)	?	0
-	70000832	Pinion Set 5th Gear Complete	-	1	£1,448.38 (Exc VAT)	?	0
-	70000833	Pinion Set 6th Gear Complete Not for CH	-	1	£1,448.38 (Exc VAT)		0
-	70000831	Pinion Set 4th Gear Complete	-	1	£1,196.44 (Exc VAT)	?	0
-	70000830	Pinion Set 3rd Gear Complete	-	1	£1,385.38 (Exc VAT)		0
1	156925	Pinion Not as spare part- -With the pinion complete kit for main shaft/1st gear and 2nd gear only	-	1	POA (Exc VAT)	?	0
2	14328401	Plug	-	1	£0.30 (Exc VAT)		0
3	14601470	Pin	-	1	POA (Exc VAT)	?	0
4	155653	Idle Gear For Reverse and Neutral Not as spare part- -With the pinion kit for Neutral/Reverse only- -Valid for pinion complete kit for Neutral/Reverse 70000829	-	1	POA (Exc VAT)	?	0
4	160942	Idle Gear For Reverse and Neutral Not as spare part- -With the pinion kit for Neutral/Reverse only- -Valid for pinion complete kit for Neutral/Reverse 70000846	-	1	POA (Exc VAT)	?	0
5	155644	RM Driving Gear Not as spare part- -With the pinion kit for Neutral/Reverse only	-	1	POA (Exc VAT)	?	0
6	157260	3rd Gear Pinion Not as spare part- -With the pinion complete kit for 3rd gear only	-	1	POA (Exc VAT)	?	0
	Superseded by 70000830	Pinion Set 3rd Gear Complete	N	1	£1,385.38 (Exc VAT)		0
7	155657	4th Gear Pinion Not as spare part- -With the pinion complete kit for 4th gear only	-	1	POA (Exc VAT)	?	0
8	155658	5th Gear Pinion Not as spare part- -With the pinion complete kit for 5th gear only	-	1	POA (Exc VAT)	?	0
9	161913	6th Gear Pinion Not as spare part- -With the pinion complete kit for 6th gear only- -Not for CH	-	1	POA (Exc VAT)	?	0
	Superseded by 70000833	Pinion Set 6th Gear Complete	N	1	£1,448.38 (Exc VAT)		0
9	155659	6th Gear Pinion Not as spare part- -With the pinion complete kit for 6th gear only- -Valid for CH	-	1	POA (Exc VAT)	?	0
10	125480	Clutch Shaft Nut 17mm Height	MP -	1	£32.26 (Exc VAT)		0
11	157179	Needle Bearing	-	1	£171.44 (Exc VAT)		0
12	107525	Double Caged Needle Bearing	-	4	£10.28 (Exc VAT)	?	0
13	151576	Gearbox Bush	-	1	POA (Exc VAT)	?	0
14	161015	Synchronizer Body	-	1	POA (Exc VAT)	?	0
15	152198	Synchro Sleeve	-	1	POA (Exc VAT)	?	0
16	155155	Synchronizer Ring (Not Grooved)	-	2	POA (Exc VAT)	?	0
17	104734	Caged Needle	-	2	£7.33 (Exc VAT)		0
18	152195	Block	-	3	£0.40 (Exc VAT)		0
19	152197	Ball	-	1	£2.09 (Exc VAT)		0
20	161016	Spring	-	3	£2.85 (Exc VAT)	?	0
21	152914	Gearbox Bush	-	1	£294.95 (Exc VAT)	?	0
22	157177	Bearing	-	1	£91.48 (Exc VAT)		0
23	138694	Spacer	-	1	£31.12 (Exc VAT)	?	0
24	163866	Bevel Gear Set Complete Valid till stock exhaustion	-	1	POA (Exc VAT)	?	0
	Superseded by 168047	Bevel Gear Set Complete	N	1	£675.99 (Exc VAT)		0
24	168047	Bevel Gear Set Complete Valid after stock exhaustion of 163866	-	1	£675.99 (Exc VAT)		0
25	157178	Bearing	-	1	£183.91 (Exc VAT)		0
26	152386	Gearbox Bush	-	1	£158.40 (Exc VAT)	?	0
27	152207	Synchronizer Body	-	1	£168.75 (Exc VAT)		0
28	152206	Synchronizer Sleeve	-	1	£76.98 (Exc VAT)	?	0
29	152209	Synchronizer Ring	-	2	£163.02 (Exc VAT)	?	0
30	152195	Block	-	3	£0.40 (Exc VAT)		0
31	152197	Ball	-	3	£2.09 (Exc VAT)		0
32	152196	Spring	-	3	£0.46 (Exc VAT)		0
33	151576	Gearbox Bush	-	1	POA (Exc VAT)	?	0
34	149365	Spacer 3.4mm	-	2	£34.39 (Exc VAT)	?	0
34	149366	Spacer 3.5mm	-	2	£41.74 (Exc VAT)	?	0
34	149367	Spacer 3.6mm	-	2	£37.66 (Exc VAT)	?	0
34	149368	Spacer 3.7mm	-	2	£10.57 (Exc VAT)	?	0
34	149369	Spacer 3.8mm	-	2	£7.89 (Exc VAT)	?	0
34	149370	Spacer 3.9mm	-	2	POA (Exc VAT)	?	0
34	149371	Spacer 4.0mm	-	2	£11.70 (Exc VAT)	?	0
34	149372	Spacer 4.1mm	-	2	£26.71 (Exc VAT)	?	0
34	153457	Spacer 4.2mm	-	2	£30.52 (Exc VAT)	?	0
34	153459	Spacer 4.3mm	-	2	£30.73 (Exc VAT)	?	0
34	164932	Spacer 4.4mm	-	2	£9.71 (Exc VAT)		0
34	164933	Spacer 4.5mm	-	2	£10.37 (Exc VAT)		0
34	168073	Spacer 4.6mm	-	2	£51.01 (Exc VAT)	?	0
35	155694	Double Ball Race Bearing	-	1	£89.17 (Exc VAT)		0
36	153000	Gearbox Locknut	MP -	1	£33.70 (Exc VAT)		0
37	109724	O-Ring	-	1	£1.00 (Exc VAT)		0
38	131335	Bearing Holder	-	1	POA (Exc VAT)	?	0
39	131015	Tapered Roller Bearing	-	1	£299.69 (Exc VAT)		0
40	131356	Bush For Bearing	-	1	POA (Exc VAT)		0
41	131388	Spacer 1.8mm	-	1	£41.41 (Exc VAT)		0
41	131389	Spacer 1.9mm	-	1	£16.21 (Exc VAT)		0
41	131390	Spacer 2.0mm	-	1	£36.84 (Exc VAT)	?	0
41	131391	Spacer 2.1mm	-	1	POA (Exc VAT)	?	0
41	131392	Spacer 2.2mm	-	1	£18.08 (Exc VAT)	?	0
41	131393	Spacer 2.3mm	-	1	POA (Exc VAT)	?	0
42	160060	Driven Gear on Pinion Not as spare part- -With the gear transmission torque- -See Table 23- -Not for CH	-	1	POA (Exc VAT)	?	0
42	156366	Driven Gear on Pinion Not as spare part- -With the gear transmission torque- -See Table 23- -Valid for CH	-	1	POA (Exc VAT)	?	0
43	157319	Spacer	-	1	£115.94 (Exc VAT)		0
44	131374	Spacer 1.8mm	-	1	£8.70 (Exc VAT)	?	0
44	131375	Spacer 1.9mm	-	1	£29.95 (Exc VAT)	?	0
44	141044	Spacer 1.95mm	-	1	£15.00 (Exc VAT)	?	0
44	131376	Spacer 2.0mm	-	1	£8.70 (Exc VAT)	?	0
44	141046	Spacer 2.05mm	-	1	£5.51 (Exc VAT)	?	0
44	131377	Spacer 2.1mm	-	1	£10.00 (Exc VAT)	?	0
44	141048	Spacer 2.15mm	-	1	£5.53 (Exc VAT)	?	0
44	131378	Spacer 2.2mm	-	1	£8.70 (Exc VAT)	?	0
44	131379	Spacer 2.3mm	-	1	£35.01 (Exc VAT)	?	0
44	157993	Spacer 2.4mm	-	1	£5.46 (Exc VAT)	?	0
44	157994	Spacer 2.5mm	-	1	£6.54 (Exc VAT)	?	0
45	131016	Roller Bearing	-	1	£79.19 (Exc VAT)	?	0
46	105137	Gearbox lock Nut M25 x 1.5	-	1	POA (Exc VAT)	?	0
	Alternative 105137/A	Gearbox Lock Nut	MP N	1	£43.64 (Exc VAT)		0
47	131425	Spacer 2.5mm Valid till gearbox Nr. 1738 and 198 CH- -Valid for R.H. lateral cover 154638- -See Table 27	-	1	£8.17 (Exc VAT)	?	0
47	165484	Spacer 2.4mm Valid till gearbox Nr. 1738 and 198 CH- -Valid for R.H. lateral cover 154638- -See Table 27	-	1	£8.17 (Exc VAT)	?	0
47	165485	Spacer 2.6mm Valid till gearbox Nr. 1738 and 198 CH- -Valid for R.H. lateral cover 154638- -See Table 27	-	1	£8.17 (Exc VAT)	?	0
47	160939	Spacer 3.4mm Valid from gearbox Nr. 1739 and 199 CH- -Valid for R.H. lateral cover 163819- -See Table 27	-	1	£6.41 (Exc VAT)	?	0
47	160929	Spacer 3.5mm Valid from gearbox Nr. 1739 and 199 CH- -Valid for R.H. lateral cover 163819- -See Table 27	-	1	£6.77 (Exc VAT)	?	0
47	160940	Spacer 3.6mm Valid from gearbox Nr. 1739 and 199 CH- -Valid for R.H. lateral cover 163819- -See Table 27	-	1	£7.25 (Exc VAT)	?	0
