030 - Front Suspension - Hub And Shock Absorbers

001 - Crankcase

002 - Crankshaft, Connecting Rods And Pistons

003 - Cylinder Head (Right)

004 - Cylinder Head (Left)

005 - Camshaft Drive System (Belts)

006 - Fuel Tanks, Pumps And Pipes

007 - Fuel Injection System

008 - Air Intakes, Filters And Manifolds

009 - Throttle Control

010 - Exhaust System

011 - Lubrication - Blow-By And Oil Reservoir

012 - Lubrication - Oil Pumps And Filters

013 - Cooling System

014 - Water Pump And Pipes

015 - Clutch And Controls

016 - Clutch Release Control

017 - Transmission Drop Gears

018 - Gearbox - Mountings And Covers

019 - Gearbox

020 - Main Shaft Gears

021 - Lay Shaft Gears

022 - Gearbox Controls

023 - Differential And Axle Shafts

024 - Brake Hydraulic System

025 - Brake System

026 - Brake Calipers For Front And Rear

027 - Hand-Brake Control

028 - Steering Rack And Linkage

029 - Steering Column

030 - Front Suspension - Hub And Shock Absorbers

031 - Front Suspension - Wishbones

032 - Rear Suspension - Hub And Brake Disc

033 - Rear Suspension - Wishbones And Shock Absorbers

034 - Wheels

035 - Engine Ignition

036 - Alternator, Starter And Battery

037 - Air Conditioning System

038 - Tool Kit

039 - Throttles Controll (For RHD Version)

040 - Clutch Release Controll (For RHD Version)

041 - Brake Hydraulic System (For RHD Version)

101 - Body Shell - Outer Elements

102 - Body Shell - Inner Elements Lower

103 - Body Shell - Inner Elements Upper

104 - Insulating Material And Bulkheads

105 - Front Compartment Lid

106 - Rear Bonnet

107 - Doors

108 - Fixed Glass

109 - Interior Trim, Accessories And Seats

110 - Tunnel And Roof

111 - Instrument Panel

112 - Instruments And Accessories

113 - Fuses And Relays

114 - Headlight Lifting Device

115 - Lights

116 - Windshield Wipers, Washer And Horns

117 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	110917	Front Road Spring	MP -	2	£388.02 (Exc VAT)		0
2	105223	Shock Absorber Dust Cover	MP -	2	£36.86 (Exc VAT)		0
3	103264	Lower Spring Pad	-	2	£29.17 (Exc VAT)		0
4	103265	N Front Shock Absorber	MP - £££	2	£318.35 (Exc VAT)		0
5	100809	Shock Absorber Mounting Bush	-	4	£16.70 (Exc VAT)		0
6	114728	Rubber	-	2	POA (Exc VAT)	?	0
7	106419	Suspension Bolt M12 x 1.25 x 71	-	2	£29.25 (Exc VAT)		0
8	16105121	Nyloc Nut	-	2	POA (Exc VAT)	?	0
	Superseded by 148020	Nut M12 x 1.25	N	2	£3.47 (Exc VAT)		0
9	104589	RH Front Stub Axle	-	1	£815.77 (Exc VAT)		0
9	104590	LH Front Stub Axle	-	1	£815.77 (Exc VAT)		0
10	103241	Suspension Bolt	MP -	2	£54.38 (Exc VAT)		0
11	16105121	Nyloc Nut	-	2	POA (Exc VAT)	?	0
12	10724621	RH Thread Castellated Nut	-	1	POA (Exc VAT)	?	0
	Alternative 92429	RH Thread Castellated Nut	MP N	1	£37.74 (Exc VAT)		0
12	11638021	LH Thread Castellated Nut	-	1	POA (Exc VAT)	?	0
	Alternative 92431	LH Thread Castellated Nut	MP N	1	£27.46 (Exc VAT)		0
13	10733801	Split pin	-	2	POA (Exc VAT)	?	0
14	101446	Washer	MP -	2	£15.50 (Exc VAT)		0
15	110150	Ring (Oil Seal Cover)	MP -	2	£96.04 (Exc VAT)		0
16	101363	Tapered Roller Bearing	MP -	2	£23.48 (Exc VAT)		0
17	115969	Sealing Ring	-	2	£76.11 (Exc VAT)		0
18	104588	Tapered Bearing	MP -	2	£38.52 (Exc VAT)		0
19	115972	RH Hub Spline Front	-	1	£1,378.94 (Exc VAT)		0
19	115971	LH Hub Spline Front	-	1	£1,378.94 (Exc VAT)		0
20	103208	Front Brake Disc 365/512Bb*Fit in pairs	MP -	2	£520.36 (Exc VAT)		0
21	110901	RH Front Brake Disc Cover	-	1	POA (Exc VAT)	?	0
21	110902	LH Front Brake Disc Cover	-	1	POA (Exc VAT)	?	0
22	16043821	Bolt 8 x 30 UNI 5737	-	16	POA (Exc VAT)	?	0
	Superseded by 16043824	Bolt M8 x 30	N	16	£0.38 (Exc VAT)		0
23	16100821	Plain Nut 8mm x 6.25mm Pitch 1.25	-	16	POA (Exc VAT)	?	0
	Superseded by 16102314	Nut M8 x 5	N	16	£0.06 (Exc VAT)		0
24	106852	Spring Washer 8mm	-	16	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	16	£0.05 (Exc VAT)		0
25	16043221	Bolt M8 x 16	-	2	£0.09 (Exc VAT)		0
26	106852	Spring Washer 8mm	-	2	POA (Exc VAT)	?	0
27	106616	Washer	-	2	£1.08 (Exc VAT)	?	0
	Superseded by 12601574	Wavy Washer 13mm	N	2	£0.06 (Exc VAT)		0
28	107494	Spacer	-	2	POA (Exc VAT)	?	0
