Ferrari / 330 GT 2+2 Mk.1 / 207A - Door Frames (From 561) (Edition 2)

Reset

< Prev Next >

207A - Door Frames (From 561) (Edition 2)

001 - Crankcase

002 - Oil Sump

003 - Crankshaft And Starter

004 - Connecting Rods

005 - Cylinder Heads

006 - Carburettor

007 - Air Inlet And Manifolds

008 - Feeding And Controls

009 - Exhaust Manifolds, Silencers And Extensions

010 - Timing

011 - Oil Pump And Filters

012 - Water Pump And Fan

013 - Distributors And Controls

014 - Wiring - Ignition Coils And Battery

015 - Generator And Engine Breathers

016 - Clutch

017 - Clutch Housing And Gear Box

018 - Intermediate Gear Box Housing

019 - Gearshift Lever

020 - Countershaft

021 - Output Shaft

022 - Overdrive And Gearbox Clamping

023 - Transmission Shaft

024 - Differential Case

025 - Rear Axle

026 - Rear Suspension

027 - Frame

028 - Front Wheel Suspension Upper Arms

029 - Front Wheel Suspension Bottom Arms

030 - Pedal Board

031 - Brake Control

032 - Double Brake Master Cylinder

033 - Front Brakes And Hubs

034 - Rear Brakes And Handbrake

035 - Tyres - Wheels - Hubs - Axle

036 - Steering Box

037 - Steering Wheel And Steering Shaft

038 - Steering Linkage

039 - Water Radiator

040 - Fuel Tank

041 - Toolkit

201 - Body Frame (Edition 1)

201A - Body Frame (Edition 2)

202 - Roof Covering & Frame

203 - Front Body Panels (Mk1 LHD Upto 566 & RHD Upto 59)

203A - Front Body Panels (Mk2 LHD From 567 & RHD From 60)

204 - Rear Body Panels (Mk1 LHD Upto 566 & RHD Upto 59)

204A - Rear Body Panels (Mk2 LHD From 567 & RHD From 60)

205 - Bonnet

206 - Electric Windows

207 - Door Frames (Upto 560) (Edition 1)

207A - Door Frames (From 561) (Edition 2)

207B - Door Frames (From 561) (Edition 1 & 2 & 3)

208 - Boot/Trunk (Edition 1)

208A - Boot/Trunk (Edition 2 & 3)

209 - Boot Carpets (Mk1 LHD Upto 566 & RHD Upto 59)

209A - Boot Carpets (Mk2 LHD From 567 & RHD From 60)

210 - Front Bumper (Mk1 LHD Upto 566 & RHD Upto 59)

210A - Front Bumper (Mk2 LHD From 567 & RHD From 60)

211 - Rear Bumper (Mk1 LHD Upto 566 & RHD Upto 59)

211A - Rear Bumper (Mk2 LHD From 567 & RHD From 60)

212 - Radiator Grille

213 - Windscreen

214 - Rear Screen

214A - Rear Qtr Light Windows

215 - External Side Trim

215A - External Side Trim

216 - Interior Carpets & Trim (Edition 1)

216A - Interior Carpets & Trim (Edition 2 & 3)

217 - Interior Insulation Felt (Edition 1)

217A - Interior Insulation Felt (Edition 2 & 3)

218 - Interior Access & Trim (Edition 1 & 2 & 3)

219 - Seats

220 - Number Plate Frames

221 - Dashboard

222 - Dashboard Switches

223 - System Electrics

224 - Front & Rear Lights (Mk1 LHD Upto 566 & RHD Upto 59)

224A - Front & Rear Lights (Mk2 LHD From 567 & RHD From 60)

225 - Wiper Components

226 - Heating & Ventilation Internal

227 - Heating & Ventilation External

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	241-30-068-00	Door Hinge Pin	-	4	POA (Exc VAT)	?	0
2	242-30-070-00	RH Upper Door Hinge	-	1	POA (Exc VAT)	?	0
2	242-30-071-00	LH Upper Door Hinge	-	1	POA (Exc VAT)	?	0
3	242-30-080-00	RH Lower Door Hinge	-	1	POA (Exc VAT)	?	0
3	242-30-081-00	LH Lower Door Hinge	-	1	POA (Exc VAT)	?	0
4	242-30-168-00	Window Moulding 0.670mm	-	2	POA (Exc VAT)	?	0
5	242-30-170-01	RH Door Lock Mechanism	-	1	£143.25 (Exc VAT)		0
5	242-30-171-01	LH Door Lock Mechanism	-	1	POA (Exc VAT)	?	0
6	242-30-174-01	RH Door Lock Housing Plate	-	1	POA (Exc VAT)	?	0
6	242-30-175-01	LH Door Lock Housing Plate	-	1	POA (Exc VAT)	?	0
7	242-30-210-01	RH Door Lock Catch Plate	-	1	POA (Exc VAT)	?	0
7	242-30-211-01	LH Door Lock Catch Plate	-	1	£19.62 (Exc VAT)	?	0
8	242-30-216-00	Joint	-	2	POA (Exc VAT)	?	0
9	691-30-240-00	RH Bush	-	2	POA (Exc VAT)	?	0
9	691-30-241-00	LH Bush	-	2	POA (Exc VAT)	?	0
10	242-30-260-02	RH Lock Barrel	-	1	POA (Exc VAT)	?	0
10	242-30-261-02	LH Lock Barrel	-	1	POA (Exc VAT)	?	0
11	239-30-266-08	RH Plate	-	2	£25.50 (Exc VAT)	?	0
11	239-30-267-08	LH Plate	-	2	£25.57 (Exc VAT)	?	0
12	242-30-162-00	Rubber Seal 0.443mm	-	2	POA (Exc VAT)	?	0
	Alternative 242-30-162-00/K	Door Base Rubber Seal Pair	N	2	£43.68 (Exc VAT)		0
13	242-30-280-02	RH Door Handle	MP -	1	POA (Exc VAT)	?	0
13	242-30-281-02	LH Door Handle	-	1	POA (Exc VAT)	?	0
14	242-30-284-00	Door Handle Gasket	MP -	2	POA (Exc VAT)	?	0
15	242-30-322-04	RH Support LHD UPTO 560	-	1	£13.02 (Exc VAT)		0
15	242-30-323-04	LH Support LHD UPTO 560	-	1	POA (Exc VAT)	?	0
15	242-30-322-11	RH Support LHD FROM 561 UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
15	242-30-323-11	LH Support LHD FROM 561 UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
16	242-30-330-01	RH Qtr Light Fixed Framework LHD UPTO 560	-	1	£93.15 (Exc VAT)	?	0
16	242-30-331-01	LH Qtr Light Fixed Framework LHD UPTO 560	-	1	£77.06 (Exc VAT)		0
16	242-30-330-11	RH Qtr Light Fixed Framework LHD FROM 561 UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
16	242-30-331-11	LH Qtr Light Fixed Framework LHD FROM 561 UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
17	242-30-334-08	RH Qtr Light Mobile Framework LHD UPTO 560	-	1	POA (Exc VAT)	?	0
17	242-30-335-08	LH Qtr Light Mobile Framework LHD UPTO 560	-	1	£111.99 (Exc VAT)		0
17	242-30-334-18	RH Qtr Light Mobile Framework LHD FROM 561 UPTO 675 - RHD UPTO 75	-	1	£72.61 (Exc VAT)		0
17	242-30-335-18	LH Qtr Light Mobile Framework LHD FROM 561 UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
18	400-30-348-02	RH Bracket LHD UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
18	400-30-349-02	LH Bracket LHD UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
19	242-30-354-00	Window Moulding	-	2	POA (Exc VAT)	?	0
20	242-30-356-00	Moulding	-	2	POA (Exc VAT)	?	0
21	242-30-358-08	RH Moulding LHD UPTO 560	-	1	POA (Exc VAT)	?	0
21	242-30-359-08	LH Moulding LHD UPTO 560	-	1	POA (Exc VAT)	?	0
22	242-30-360-00	Top Window Moulding	-	2	POA (Exc VAT)	?	0
23	690-30-362-02	RH Qtr Light Inner Lever LHD UPTO 675 - RHD UPTO 75	-	1	POA	?	0
23	690-30-363-02	LH Qtr Light Inner Lever LHD UPTO 675 - RHD UPTO 75	-	1	POA	?	0
24	242-30-364-02	Handle Support LHD UPTO 560	-	2	POA (Exc VAT)	?	0
24	400-30-364-02	Handle Support LHD FROM 561 UPTO 675 - RHD UPTO 75	-	2	POA (Exc VAT)	?	0
25	690-30-367-02	Screw LHD UPTO 675 - RHD UPTO 75	-	2	POA (Exc VAT)	?	0
26	400-30-366-04	Qtr Light Handle Spring LHD UPTO 675 - RHD UPTO 75	-	2	POA (Exc VAT)	?	0
27	242-30-372-10	RH Front Qtr Light Rubber LHD FROM 561	-	1	POA (Exc VAT)	?	0
	Alternative 242-30-372-10/K	RH + LH Front Qtr Light Rubber Set	N	1	£583.30 (Exc VAT)		0
27	242-30-373-00	LH Front Qtr Light Rubber LHD FROM 561	MP -	1	£307.95 (Exc VAT)		0
29	400-30-380-02	Handle LHD UPTO 675 - RHD UPTO 75	-	2	POA (Exc VAT)	?	0
31	242-30-406-08	RH Cover	-	1	POA (Exc VAT)	?	0
31	242-30-407-08	LH Cover	-	1	POA (Exc VAT)	?	0
32	242-30-408-08	RH Cover	-	1	POA (Exc VAT)	?	0
32	242-30-409-08	LH Cover	-	1	POA (Exc VAT)	?	0
33	242-30-410-08	RH Outer & LH Inner Cover	-	2	POA (Exc VAT)	?	0
33	242-30-411-08	LH Outer & RH Inner Cover	-	2	POA (Exc VAT)	?	0
34	242-30-412-08	RH Moulding LHD UPTO 330	-	1	POA (Exc VAT)	?	0
34	242-30-413-08	LH Moulding LHD UPTO 330	-	1	POA (Exc VAT)	?	0
34	242-30-412-18	RH Cover LHD FROM 331	-	1	POA (Exc VAT)	?	0
34	242-30-413-18	LH Cover LHD FROM 331	-	1	POA (Exc VAT)	?	0
35	242-30-422-08	RH Moulding LHD UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
35	242-30-423-08	LH Moulding LHD UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
35	242-30-422-18	RH Moulding LHD FROM 676 - RHD FROM 76	-	1	POA (Exc VAT)	?	0
35	242-30-423-18	LH Moulding LHD FROM 676 - RHD FROM 76	-	1	POA (Exc VAT)	?	0
36	242-30-434-08	RH Upper Cover LHD UPTO 330	-	1	POA (Exc VAT)	?	0
36	242-30-435-08	LH Upper Cover LHD UPTO 330	-	1	POA (Exc VAT)	?	0
36	242-30-434-18	RH Upper Cover LHD FROM 331	-	1	POA (Exc VAT)	?	0
36	242-30-435-18	LH Upper Cover LHD FROM 331	-	1	POA (Exc VAT)	?	0
37	242-30-476-01	RH Bracket	-	1	POA (Exc VAT)	?	0
37	242-30-477-01	LH Bracket	-	1	£50.55 (Exc VAT)		0
38	242-30-486-00	Moulding	-	2	POA (Exc VAT)	?	0
39	242-30-502-01	Bracket	-	2	POA (Exc VAT)	?	0
40	0-918-1-079-1	Screw	-	2	£0.29 (Exc VAT)		0
41	242-30-510-00	Drop Glass 330Gt	-	2	POA (Exc VAT)	?	0
42	242-30-512-00	Window Rubber	-	2	POA (Exc VAT)	?	0
43	242-30-528-00	RH & LH Front Qtr Glass LHD UPTO 560	-	2	£108.19 (Exc VAT)		0
43	242-30-528-10	RH & LH Front Qtr Glass LHD FROM 561 UPTO 675 - RHD UPTO 75	-	2	POA (Exc VAT)	?	0
44	242-30-540-03	RH Window Regulator	-	1	POA (Exc VAT)	?	0
44	242-30-541-03	LH Window Regulator	-	1	POA (Exc VAT)	?	0
45	242-30-544-01	RH Window Channel	-	1	POA (Exc VAT)	?	0
45	242-30-545-01	LH Window Channel	-	1	POA (Exc VAT)	?	0
46	135-30-576-01	Window Winder Wheel	-	2	£5.03 (Exc VAT)	?	0
47	400-30-588-01	Pin	-	2	POA (Exc VAT)	?	0
48	242-30-592-00	RH Internal Panel LHD UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
48	242-30-593-00	LH Internal Panel LHD UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
48	242-30-592-10	RH Panel LHD FROM 676 - RHD FROM 76	-	1	POA (Exc VAT)	?	0
48	242-30-593-10	LH Panel LHD FROM 676 - RHD FROM 76	-	1	POA (Exc VAT)	?	0
49	242-30-634-02	Door Light	-	2	POA (Exc VAT)	?	0
50	242-30-660-08	RH Moulding	-	1	POA (Exc VAT)	?	0
50	242-30-661-08	LH Moulding	-	1	POA (Exc VAT)	?	0
51	242-30-662-08	RH Moulding	-	1	POA (Exc VAT)	?	0
51	242-30-663-08	LH Moulding	-	1	POA (Exc VAT)	?	0
52	400-30-668-01	Door Trim Clip	-	22	POA (Exc VAT)	?	0
53	242-30-674-01	RH Panel	-	1	POA (Exc VAT)	?	0
53	242-30-675-01	LH Panel	-	1	POA (Exc VAT)	?	0
54	242-30-700-00	RH Armrest RHD RHD UPTO 75	-	1	POA (Exc VAT)	?	0
54	242-30-701-00	LH Armrest LHD LHD UPTO 675	-	1	POA (Exc VAT)	?	0
54	244-30-700-00	RH Armrest RHD RHD FROM 76	-	1	POA (Exc VAT)	?	0
54	242-30-701-10	LH Armrest LHD LHD FROM 676	-	1	POA (Exc VAT)	?	0
55	242-30-812-02	RH Internal Door Handle Plate	-	1	POA (Exc VAT)	?	0
55	242-30-813-02	LH Internal Door Handle	-	1	POA (Exc VAT)	?	0
56	242-28-414-01	RH Clip	-	1	POA (Exc VAT)	?	0
56	242-28-415-01	LH Clip	-	1	POA (Exc VAT)	?	0
57	242-30-830-02	Inner Door Handle Surround	-	2	£45.48 (Exc VAT)	?	0
58	242-30-850-02	RH Window Winder Handle	-	1	POA (Exc VAT)	?	0
58	242-30-851-02	LH Window Winder Handle	-	1	£41.98 (Exc VAT)	?	0
59	242-30-852-02	Washer	-	2	£3.45 (Exc VAT)	?	0
60	242-30-898-00	RH Moulding LHD UPTO 675 - RHD UPTO 75	-	1	£143.32 (Exc VAT)	?	0
60	242-30-899-00	LH Moulding LHD UPTO 675 - RHD UPTO 75	-	1	POA (Exc VAT)	?	0
60	242-30-898-10	RH Moulding LHD FROM 676 - RHD FROM 76	-	1	POA (Exc VAT)	?	0
60	242-30-899-10	LH Moulding LHD FROM 676 - RHD FROM 76	-	1	POA (Exc VAT)	?	0
61	242-30-916-08	RH Moulding	-	1	POA (Exc VAT)	?	0
61	242-30-917-08	LH Moulding	-	1	POA (Exc VAT)	?	0
62	400-30-946-00	Plug	-	4	POA (Exc VAT)	?	0
63	691-30-962-01	Check Strap	-	2	POA (Exc VAT)	?	0
64	242-30-978-01	Door Stop	-	2	POA (Exc VAT)	?	0
65	242-30-198-00	Knob	-	2	POA (Exc VAT)	?	0
66	242-30-192-08	Clip	-	2	POA (Exc VAT)	?	0
