Ferrari / 308 Quattrovalvole USA / 103 - Body Shell - Inner Elements

Reset

< Prev Next >

001 - Engine - Gearbox and Supports

002 - Crankcase

003 - Crankshaft - Connecting rods and pistons

004 - Flywheel and Clutch Housing Spacer

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Air Injection

010 - Antievaporative Emission Control System

011 - Fuel Pump and Pipes

012 - Fuel Injection System - Fuel Distributors Lines

013 - Air Intake and Manifolds

014 - Throttle Housing and Linkage

015 - Exhaust System

016 - Blow - By System

017 - Lubrication System

018 - Cooling System

019 - Water Pump and Pipings

020 - Clutch and Control

021 - Gearbox Transmission

022 - Gearbox - Differential Housing and Oil Sump

023 - Main Shaft Gears

024 - Lay Shaft Gears

025 - Inside Gearbox Controls

026 - Outside Gearbox Controls

027 - Differential and Axle Shafts

028 - Pedal Board - Brake and Clutch Controls

029 - Brake System

030 - Calipers for Front and Rear Brakes

031 - Hand - Brake Control

032 - Steering Box and Linkage

033 - Steering Column

034 - Front Suspension - Shock Absorber and Brake Disc

035 - Front Suspension - Wishbones

036 - Rear Suspension - Shock Absorber and Brake Disc

037 - Rear Suspension - Wishbones

038 - Wheels

039 - Engine Ignition

040 - Electric Generating System

041 - Air Conditioning System

042 - Air Conditioning Compressor and Controls

043 - Tool - Kit

101 - Body Shell - Outer Elements

102 - Body Shell - Inner Elements

103 - Body Shell - Inner Elements

104 - Passenger and Luggage Compartments Insulation

105 - Front Compartment Lid

106 - Rear Bonnet and Luggage Compartment Covering

107 - Doors

108 - Bumpers and Mouldings

109 - Glasses

110 - Interior Trim - Accessories and Seats

111 - Tunnel and Roof

112 - Instrument Panel

113 - Instruments and Accessories

114 - Fuses and Relays

115 - Electrical System

116 - Headlights Lifting Device

117 - Windshield Wiper Washer and Horn

118 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
-	60370905	Internal Roof Panel Complete GTB GTB	-	1	£949.38 (Exc VAT)	?	0
1	60260205	RH Roof Frame Tubing GTB GTB	-	1	£164.63 (Exc VAT)		0
2	60260304	LH Roof Frame Tubing GTB GTB	-	1	POA (Exc VAT)	?	0
3	60350808	RH Stiffening	-	1	POA (Exc VAT)	?	0
4	60350907	LH Stiffening LHD	-	1	POA (Exc VAT)	?	0
	Alternative 60350709	Reinforcement	N	1	£13.33 (Exc VAT)		0
5	61301600	Bracket	-	1	£8.43 (Exc VAT)		0
6	40111601	Support	-	1	£41.32 (Exc VAT)		0
7	60770600	RH Shield Panel Standard Spoiler	-	1	£33.11 (Exc VAT)		0
7	60770700	LH Shield Panel Standard Spoiler	-	1	£43.47 (Exc VAT)		0
7	60417508	RH Shield Panel Big Spoiler	-	1	£16.48 (Exc VAT)		0
7	60417607	LH Shield Panel Big Spoiler	-	1	£16.48 (Exc VAT)		0
8	60371309	Roof Support Rail GTB GTB	-	1	£176.94 (Exc VAT)		0
9	60003803	RH Outer Sill Panel	MP -	1	POA (Exc VAT)	?	0
9	60003902	LH Outer Sill Panel	MP -	1	POA (Exc VAT)	?	0
10	60296001	Roll Bar	MP -	1	£98.53 (Exc VAT)		0
11	60301603	Front Frame Usa	-	1	£184.41 (Exc VAT)		0
12	61128800	Roof Assy GTS GTS	-	1	POA (Exc VAT)	?	0
	Superseded by 60879800	Top Assy GTS	N	1	£1,650.89 (Exc VAT)		0
13	60652000	RH Frame	-	1	£138.31 (Exc VAT)		0
13	60652100	LH Frame	-	1	£150.33 (Exc VAT)		0
14	60291408	RH Shield	-	1	£24.40 (Exc VAT)		0
15	60291705	LH Shield	-	1	£26.68 (Exc VAT)		0
16	60260106	RH Rail GTB	-	1	£110.25 (Exc VAT)		0
17	60260007	LH Rail GTB	-	1	POA (Exc VAT)	?	0
18	60252400	RH Door Hinge Post	-	1	£36.91 (Exc VAT)		0
18	60252509	LH Door Hinge Post	-	1	POA (Exc VAT)	?	0
19	60289303	Support	-	2	£5.80 (Exc VAT)		0
20	60064201	Space Frame Support	-	1	£19.26 (Exc VAT)		0
21	61009800	RH Pillar Insert GTB GTB	-	1	POA (Exc VAT)	?	0
	Superseded by 60397106	RH Pillar Insert GTS	N	1	£30.30 (Exc VAT)		0
21	61009900	LH Pillar Insert GTB GTB	-	1	POA (Exc VAT)	?	0
	Superseded by 60397205	LH Pillar Insert GTS	N	1	£30.30 (Exc VAT)		0
21	60397106	RH Pillar Insert GTS GTS	-	1	£30.30 (Exc VAT)		0
21	60397205	LH Pillar Insert GTS GTS	-	1	£30.30 (Exc VAT)		0
22	60303203	RH Door Sill Assy GTB GTB	-	1	POA (Exc VAT)	?	0
22	60303302	LH Door Sill Assy GTB GTB	-	1	POA (Exc VAT)	?	0
22	60419504	RH Door Sill Assy GTS GTS	-	1	POA (Exc VAT)	?	0
22	60419603	LH Door Sill Assy GTS GTS	-	1	POA (Exc VAT)	?	0
23	61421400	Tube	-	1	POA (Exc VAT)	?	0
24	60285202	Bracket	-	2	£89.75 (Exc VAT)		0
25	60295201	RH Side GTB GTB	-	1	POA (Exc VAT)	?	0
	Superseded by 60302403	RH Panel GTB	N	1	£111.64 (Exc VAT)		0
25	60432002	RH Side Panel GTS GTS	-	1	£41.32 (Exc VAT)		0
25	60295300	LH Side GTB GTB	-	1	POA (Exc VAT)	?	0
25	60432101	LH Side GTS GTS	-	1	£41.32 (Exc VAT)		0
26	60347705	Support	-	2	£26.85 (Exc VAT)		0
27	60260403	RH Upright Panel GTB GTB	-	1	£80.51 (Exc VAT)		0
28	60260502	LH Upright Panel GTB GTB	-	1	£230.26 (Exc VAT)		0
29	60422805	Space Frame	-	1	£372.07 (Exc VAT)		0
30	60652200	Bracket	-	4	£33.95 (Exc VAT)		0
31	60351202	Reinforcement	-	1	£215.68 (Exc VAT)		0
32	60371705	Bracket GTB	-	1	£14.83 (Exc VAT)		0
33	60371002	Reinforcement GTB	-	1	£5.80 (Exc VAT)		0
34	60361805	Spire Clip	-	4	£1.22 (Exc VAT)		0
35	60284304	Plug	-	2	POA (Exc VAT)	?	0
