Ferrari / 308 GTB/GTS JAP / 034 - Handbrake Control

Reset

< Prev Next >

001 - Engine - Gearbox and Supports

002 - Crankcase

003 - Crankshaft - Connecting rods and pistons

004 - Flywheel and Clutch Housing Spacer

005 - Cylinder Head (Right)

006 - Cylinder Head (Left)

007 - Timing System - Tappets

008 - Timing System - Controls

009 - Air Pump & Pipings

010 - Guards

011 - Antievaporative Emission Control System

012 - Fuel Pump & Pipes

013 - Intake Air Cleaner Valve & Lines

014 - Carburettors & Air Filter

015 - Weber 40 DCNF 72,73,74,75 100

016 - Throttle Control

017 - Exhaust System

018 - Blow - By System

019 - Lubrication System

020 - Cooling System

021 - Water Pump & Pipings

022 - Clutch Operating Control

023 - Clutch Unit & Cover

024 - Gearbox Transmission

025 - Gearbox - Differential Housing & Oil Sump

026 - Main Shaft Gears

027 - Lay Shaft Gears

028 - Inside Gearbox Controls

029 - Outside Gearbox Controls

030 - Differential & Axle Shafts

031 - Pedal Board - Brake & Clutch Controls

032 - Brake System

033 - Calipers for Front & Rear Brakes

034 - Handbrake Control

035 - Steering Box & Linkage

036 - Steering Column

037 - Front Suspension - Shock Absorber & Brake Disc

038 - Front Suspension - Wishbones

039 - Rear Suspension - Shock Absorber & Brake Disc

040 - Rear Suspension - Wishbones

041 - Wheels

042 - Engine Ignition

043 - Electric Generating System

044 - Air Conditioning System

045 - Air Conditioning Compressor & Controls

046 - Toolkit

102 - Body Shell - Outer Elements

103 - Body Shell - Inner Elements

104 - Body Shell - Inner Elements

105 - Passenger & Luggage Compartments Insulation

106 - Front Compartment Lid

107 - Rear Bonnet & Luggage Compartment Covering

108 - Doors

109 - Bumpers & Mouldings

110 - Glasses

111 - Interior Trim Accessories & Seats

112 - Tunnel & Roof

113 - Instrument Panel

114 - Carpeting

115 - Instruments & Accessories

116 - Body Electrical

117 - Fuses & Relays

118 - Headlights Lifting Device

119 - Lights

120 - Windshield Wiper Washer & Horn

121 - Heating System

Show Selected Clear Selection Add to Basket

Show Clear Add

0 Parts‚ Price £0.00 (Exc VAT)

No.	Part	Name		FQ	Price
Multiple variants of the same part are selected for items:
1	109225	Handbrake Lever	-	1	POA (Exc VAT)	?	0
2	16043221	Bolt M8 x 16	-	3	£0.09 (Exc VAT)		0
3	10519621	Washer	-	3	POA (Exc VAT)	?	0
	Superseded by 10519624	Washer 8.15-17x2	N	3	£0.11 (Exc VAT)		0
4	106852	Spring Washer 8mm	-	3	POA (Exc VAT)	?	0
	Superseded by 127496	Spring Washer 8mm	N	3	£0.05 (Exc VAT)		0
5	10725911	RH Thread Nut 6mm filetto Dx	-	1	POA (Exc VAT)	?	0
	Superseded by 10725914	Nut M6 x 4	N	1	£0.09 (Exc VAT)		0
6	10727311	LH Thread Nut 6mm filetto Sx	-	1	POA (Exc VAT)	?	0
	Superseded by 10727314	Nut 6mm	MP N	1	£5.51 (Exc VAT)		0
7	107618	Washer 8-15 x 1	-	1	£1.48 (Exc VAT)		0
8	106852	Spring Washer 8mm	-	2	POA (Exc VAT)	?	0
9	101188	Handbrake Switch	-	1	POA (Exc VAT)	?	0
	Alternative 802-80-816-00	Glove Box Switch	N	1	£3.77 (Exc VAT)		0
10	106482	Handbrake Cable LHD	MP -	1	POA (Exc VAT)	?	0
	Alternative 107470	Front Handbrake Cable RHD	N	1	£45.51 (Exc VAT)		0
11	10734201	Split Pin	-	3	POA (Exc VAT)	?	0
	Superseded by 10734208	Split Pin D. 2 x 12	N	3	£0.02 (Exc VAT)		0
12	12625201	Washer	-	1	POA (Exc VAT)	?	0
	Superseded by 12625224	Washer	N	1	£0.06 (Exc VAT)		0
13	113056	Lever Vale dopo esaur. N. 111349	-	1	£288.13 (Exc VAT)		0
14	106416	Washer	-	2	POA (Exc VAT)	?	0
15	10091011	Adjuster	-	1	£145.97 (Exc VAT)		0
16	11066476	Circlip	-	1	£0.49 (Exc VAT)	?	0
17	106415	Support	-	1	£173.68 (Exc VAT)		0
18	16044621	Bolt	-	2	POA (Exc VAT)	?	0
19	16100811	Nut 8x6.5mm	-	2	POA (Exc VAT)	?	0
	Superseded by 16100824	Nut M8 x 6.5	N	2	£0.12 (Exc VAT)		0
20	10519601	Washer 8.15-17 X 2	-	3	£0.05 (Exc VAT)	?	0
	Superseded by 10519624	Washer 8.15-17x2	N	3	£0.11 (Exc VAT)		0
21	103227	Bush	-	2	POA (Exc VAT)	?	0
22	106170	Fork	-	1	£51.63 (Exc VAT)		0
23	10050811	Clevis Pin	-	1	POA (Exc VAT)	?	0
24	105789	Pin	-	1	£122.61 (Exc VAT)		0
25	16100811	Nut 8x6.5mm	-	1	POA (Exc VAT)	?	0
26	106852	Spring Washer 8mm	-	1	POA (Exc VAT)	?	0
27	104006	Wheel Sheave	-	2	£15.54 (Exc VAT)		0
28	105790	Plate	-	2	POA (Exc VAT)	?	0
29	12574211	Nyloc Nut M6x1	-	2	POA (Exc VAT)	?	0
	Superseded by 102948	Nyloc Nut M6 x 8	N	2	£0.19 (Exc VAT)		0
30	105791	Wheel Serve per leva n. 111349	-	1	POA (Exc VAT)	?	0
31	101195	Clevis Pin Serve per leva n. 111349	MP -	1	£24.58 (Exc VAT)		0
32	112891	Handbrake Cable Long	-	1	£104.64 (Exc VAT)		0
33	112892	Handbrake Cable Short	-	1	£96.43 (Exc VAT)		0
