No.	Part	Name		FQ	Price	Req.	Sel.
Multiple variants of the same part are selected for items:
No.	Part	Name		FQ	Price	Req.	Sel.
Multiple variants of the same part are selected for items:
1	121230	Clutch Pedal	-	1	£95.46 (Exc VAT)				0
2	106949	Pedal Rubber	MP -	1	£20.99 (Exc VAT)				0
3	103163	Bush	-	2	£5.31 (Exc VAT)				0
4	119331	Gasket	-	1	£9.19 (Exc VAT)				0
5	123961	Pin	-	1	POA (Exc VAT)			?	0
6	16102311	RH Thread Nut	-	1	£0.19 (Exc VAT)			?	0
	Superseded by 16102314	Nut M8 x 5	N	1	£0.06 (Exc VAT)				0
7	114825	Pin	-	1	£38.43 (Exc VAT)				0
8	16100821	Plain Nut 8mm x 6.25mm Pitch 1.25	-	1	POA (Exc VAT)			?	0
	Superseded by 16102314	Nut M8 x 5	N	1	£0.06 (Exc VAT)				0
9	12601371	Washer	-	1	POA (Exc VAT)			?	0
	Superseded by 12601374	Wavy Washer 8mm	N	1	£0.02 (Exc VAT)				0
10	114828	Pin	-	1	£39.78 (Exc VAT)				0
11	114826	Clutch Pedal Return Spring	-	1	£47.02 (Exc VAT)				0
12	109407	Spherical Joint D.8-16X5	-	2	£40.99 (Exc VAT)				0
13	121209	Fork	-	1	POA (Exc VAT)			?	0
	Superseded by 121212	Tie Rod	N	1	£198.32 (Exc VAT)				0
14	10050810	Pin	-	2	POA (Exc VAT)			?	0
15	10519601	Washer 8.15-17 X 2	-	1	£0.05 (Exc VAT)			?	0
	Superseded by 10519624	Washer 8.15-17x2	N	1	£0.12 (Exc VAT)				0
16	10734201	Split Pin	-	2	POA (Exc VAT)			?	0
	Superseded by 10734208	Split Pin D. 2 x 12	N	2	£0.02 (Exc VAT)				0
17	121233	Lever	-	1	£77.83 (Exc VAT)				0
18	115430	Roller Bearing	-	2	£12.60 (Exc VAT)				0
19	114830	Pin	-	1	£11.12 (Exc VAT)				0
20	112126	Washer	-	1	£0.34 (Exc VAT)				0
21	16105121	Nyloc Nut	-	1	POA (Exc VAT)			?	0
	Superseded by 148020	Nut M12 x 1.25	N	1	£3.69 (Exc VAT)				0
22	113500	Washer	-	2	£10.25 (Exc VAT)				0
23	124469	Spacer	-	1	£3.41 (Exc VAT)				0
24	123416	Clutch Master Cylinder	-	1	POA (Exc VAT)			?	0
	Superseded by 175211	Clutch Master Cylinder	N	1	£219.99 (Exc VAT)				0
25	12354521	Stud	-	2	POA (Exc VAT)			?	0
	Superseded by 12354524	Stud M8 x 16 Gambo 22mm	N	2	£24.99 (Exc VAT)				0
26	16104111	Nut	-	2	POA (Exc VAT)			?	0
	Superseded by 104030	Nyloc Nut M8 x 1.25 x 9.5	N	2	£0.21 (Exc VAT)				0
27	16102311	RH Thread Nut	-	1	£0.19 (Exc VAT)			?	0
28	10007871	Fork	-	1	£11.99 (Exc VAT)			?	0
29	12642701	Washer	-	1	£0.24 (Exc VAT)				0
30	11065676	Circlip	-	1	£0.04 (Exc VAT)				0
31	125284	Feed Pipe	-	1	POA (Exc VAT)			?	0
32	12179190	Clip	-	2	POA (Exc VAT)			?	0
33	123247	Pedal Support Housing LHD	-	1	£328.48 (Exc VAT)				0
34	124777	Bush	-	2	£14.07 (Exc VAT)				0
35	112152	Pin	-	1	£156.83 (Exc VAT)				0
36	124687	Bush	-	2	£5.90 (Exc VAT)				0
37	124686	Bush	-	1	£5.17 (Exc VAT)				0
38	11066676	Circlip	-	1	£0.15 (Exc VAT)				0
39	10519620	Washer	-	3	POA (Exc VAT)			?	0
	Superseded by 10519624	Washer 8.15-17x2	N	3	£0.12 (Exc VAT)				0
40	106852	Spring Washer 8mm	-	5	POA (Exc VAT)			?	0
	Superseded by 127496	Spring Washer 8mm	N	5	£0.05 (Exc VAT)				0
41	16043821	Bolt 8 x 30 UNI 5737	-	3	POA (Exc VAT)			?	0
	Superseded by 16043824	Bolt M8 x 30	N	3	£0.40 (Exc VAT)				0
42	16043421	Bolt	-	2	POA (Exc VAT)			?	0
	Superseded by 16043424	Bolt M8 x 20	N	2	£0.17 (Exc VAT)				0
43	11500121	Threaded Stud	-	4	POA (Exc VAT)			?	0
44	12574221	Nyloc Nut	-	4	POA (Exc VAT)			?	0
	Superseded by 102948	Nyloc Nut M6 x 8	N	4	£0.20 (Exc VAT)				0
45	141531	Spring	-	1	£14.23 (Exc VAT)				0

Make an Enquiry Report an Issue

Part Availability Key

In Stock

In Stock - Supersession (Supersession price shown)

In Stock - Alternative (Alternative price shown)

In Stock - Partial Stock

Enquire

Recently Viewed

Ferrari / Testarossa TR 90 / 029 - Clutch Release Control
