No. | Part | Name | FQ | Price | Req. | Sel. | |||||
---|---|---|---|---|---|---|---|---|---|---|---|
Multiple variants of the same part are selected for items: |
|||||||||||
No. | Part | Name | FQ | Price | Req. | Sel. | |||||
Multiple variants of the same part are selected for items: |
|||||||||||
1 | 155674 |
Selector Cover
|
-
|
1 | £219.99 (Exc VAT) |
0 | |||||
2 | 15896214 |
Nut M6 x 5
|
-
|
4 | £0.03 (Exc VAT) |
0 | |||||
Superseded by 14039614 |
Flange Nut
|
N
|
4 | £0.19 (Exc VAT) |
|
0 | |||||
3 | 12601274 |
Wavy Washer 6mm
|
-
|
4 | £0.47 (Exc VAT) |
|
0 | ||||
4 | 153647 |
Bushing
|
-
|
4 | £5.39 (Exc VAT) |
0 | |||||
5 | 153719 |
Pin
|
-
|
4 | POA (Exc VAT) |
0 | |||||
6 | 153442 |
Spacer
|
-
|
2 | £2.49 (Exc VAT) |
0 | |||||
7 | 156863 |
Rm Control Rod
|
-
|
1 | £66.99 (Exc VAT) |
0 | |||||
8 | 143341 |
Roller Bearing
|
-
|
9 | £4.09 (Exc VAT) |
0 | |||||
9 | 150411 |
Rm Control Fork
|
-
|
1 | £82.99 (Exc VAT) |
0 | |||||
10 | 155870 |
Rm Control Fork
|
-
|
1 | £139.99 (Exc VAT) |
0 | |||||
11 | 127496 |
Spring Washer 8mm
|
-
|
8 | £0.05 (Exc VAT) |
|
0 | ||||
12 | 16043634 |
Screw M8 x 25
|
-
|
4 | £0.18 (Exc VAT) |
|
0 | ||||
13 | 16043734 |
Screw
|
-
|
4 | £2.39 (Exc VAT) |
0 | |||||
14 | 156665 |
1St/2Nd Control Rod
|
-
|
1 | £76.99 (Exc VAT) |
0 | |||||
15 | 150346 |
1St/2Nd Rod Fork
|
-
|
1 | £75.99 (Exc VAT) |
0 | |||||
16 | 155800 |
1St/2Nd Control Fork
|
-
|
1 | £139.99 (Exc VAT) |
0 | |||||
17 | 156846 |
3Rd/4Th Selector Rod
|
-
|
1 | £63.99 (Exc VAT) |
0 | |||||
18 | 150521 |
3Rd/4Th Rod Fork
|
-
|
1 | £79.99 (Exc VAT) |
0 | |||||
19 | 155857 |
3Rd/4Th Control Fork
|
-
|
1 | £139.99 (Exc VAT) |
0 | |||||
20 | 156851 |
5Th/6Th Selector Rod
|
-
|
1 | £63.99 (Exc VAT) |
0 | |||||
21 | 150447 |
5Th/6Th Rod Fork
|
-
|
1 | £81.99 (Exc VAT) |
0 | |||||
22 | 155816 |
5Th/6Th Selector Fork
|
-
|
1 | £139.99 (Exc VAT) |
0 | |||||
23 | 156868 |
Gear Selector Rod
|
-
|
1 | £139.99 (Exc VAT) |
0 | |||||
24 | 155473 |
Gear Selector Connection
|
-
|
1 | POA (Exc VAT) |
0 | |||||
25 | 127496 |
Spring Washer 8mm
|
-
|
2 | £0.05 (Exc VAT) |
|
0 | ||||
26 | 16043624 |
Screw M8 x 25
|
-
|
2 | £0.17 (Exc VAT) |
|
0 | ||||
27 | 147572 |
Rubber Boot
|
-
|
1 | £82.99 (Exc VAT) |
|
0 | ||||
28 | 146306 |
Oil Seal
|
-
|
1 | £1.59 (Exc VAT) |
|
0 | ||||
29 | 143775 |
Selector Bush
|
-
|
4 | POA (Exc VAT) |
0 | |||||
Superseded by 149907 |
Bush
|
N
|
4 | £29.99 (Exc VAT) |
|
0 | |||||
30 | 157054 |
Union
|
-
|
1 | £29.99 (Exc VAT) |
0 | |||||
31 | 153722 |
Washer
|
-
|
1 | POA (Exc VAT) |
0 | |||||
32 | 121805 |
Spring
|
-
|
1 | £1.19 (Exc VAT) |
0 | |||||
Superseded by 131146 |
Spring
|
N
|
1 | £3.47 (Exc VAT) |
|
0 | |||||
33 | 101612 |
Ball
|
-
|
1 | £0.81 (Exc VAT) |
0 | |||||
34 | 154250 |
Spacer
|
-
|
2 | £4.79 (Exc VAT) |
0 | |||||
35 | 150627 |
Selector Rockerarm
|
-
|
1 | £499.99 (Exc VAT) |
0 | |||||
36 | 150606 |
Selector Lever
|
-
|
1 | £84.99 (Exc VAT) |
0 | |||||
37 | 127497 |
Spring Washer 10mm
|
-
|
1 | £0.05 (Exc VAT) |
|
0 | ||||
38 | 133150 |
Screw
|
-
|
1 | £4.79 (Exc VAT) |
0 | |||||
39 | 153999 |
Spring
|
-
|
1 | £8.09 (Exc VAT) |
0 | |||||
40 | 154246 |
Support
|
-
|
1 | £62.99 (Exc VAT) |
0 | |||||
41 | 154291 |
Screw
|
-
|
2 | £1.69 (Exc VAT) |
|
0 | ||||
42 | 10298050 |
Gasket
|
-
|
2 | £3.39 (Exc VAT) |
|
0 | ||||
43 | 12647801 |
Washer
|
-
|
2 | £1.19 (Exc VAT) |
0 | |||||
44 | 106850 |
Spring Washer 6mm
|
-
|
2 | POA (Exc VAT) |
0 | |||||
Superseded by 127494 |
Wavy Washer 6mm Zinc Coated
|
N
|
2 | £0.07 (Exc VAT) |
|
0 | |||||
45 | 15896214 |
Nut M6 x 5
|
-
|
2 | £0.03 (Exc VAT) |
0 | |||||
46 | 166560 |
Seeger
|
-
|
1 | £0.25 (Exc VAT) |
0 | |||||
47 | 10158501 |
Plug
|
-
|
1 | POA (Exc VAT) |
0 |
