No.	Part	Name		FQ	Price	Req.	Sel.
Multiple variants of the same part are selected for items:
No.	Part	Name		FQ	Price	Req.	Sel.
Multiple variants of the same part are selected for items:
1	108927	Crankcase Complete Non vale per GTS e AUS	-	1	POA (Exc VAT)			?	0
1	109088	Crankcase Complete Vale per GTS. Non vale per AUS	-	1	POA (Exc VAT)			?	0
	Superseded by 115540	Crankcase Complete	N	1	£5,812.41 (Exc VAT)				0
1	107106	Crankcase Complete Vale solo per AUS	-	1	POA (Exc VAT)			?	0
	Superseded by 115540	Crankcase Complete	N	1	£5,812.41 (Exc VAT)				0
1	109282	Crankcase Vale fino ad esaurimento - Col torn pi ess ivo n. 108927	-	1	POA (Exc VAT)			?	0
1	108928	Crankcase Vale dopo esaur. n. 109282 - Col complessivo n. 108927	-	1	POA (Exc VAT)			?	0
1	109760	Crankcase Col complessivo n. 109088	-	1	POA (Exc VAT)			?	0
	Alternative 121286	Crankcase Complete	N	1	£5,812.41 (Exc VAT)				0
1	103536	Crankcase Col eomplessivo n. 107106	-	1	£6,712.94 (Exc VAT)				0
2	103764	Main Bearing Cap per GTS e AUS q = 3 - Col basamento completo	-	2	POA (Exc VAT)			?	0
3	103765	Main Bearing Cap col basamento completo	-	1	POA (Exc VAT)			?	0
4	103766	Main Bearing Cap vale per GTS e AUS - col basamento completo	-	1	POA (Exc VAT)			?	0
4	109293	Mains Bearng Cap Non vale per GTS e AUS - Col basamento completo	-	1	POA (Exc VAT)			?	0
5	103841	Nut	-	10	POA (Exc VAT)			?	0
6	103842	Washer	-	10	POA (Exc VAT)			?	0
	Superseded by 6103842	Washer	N	10	£10.13 (Exc VAT)				0
7	104075	Stud Bolt	-	10	£9.59 (Exc VAT)				0
8	100098	Threaded Stud Per GTS e AUS q = 20	MP -	18	£31.76 (Exc VAT)				0
9	100101	Cylinder Head Nut	MP -	20	POA (Exc VAT)			?	0
	Alternative 100101/A	Cylinder Head Nut	MP N	20	£13.35 (Exc VAT)				0
10	100100	Washer	MP -	20	£3.81 (Exc VAT)				0
11	100097	Dowel 3mm id	MP -	4	£9.51 (Exc VAT)				0
12	13517221	Threaded Stud	-	6	POA (Exc VAT)			?	0
13	13516921	LH Threaded Stud	-	2	POA (Exc VAT)			?	0
	Superseded by 13516924	Stud M8 x 12 Gambo 22	N	2	£1.99 (Exc VAT)				0
13	13516821	RH Threaded Stud	-	1	POA (Exc VAT)			?	0
	Superseded by 13516824	Stud M8 x 12 Gambo 20	N	1	£0.41 (Exc VAT)				0
14	16100811	Nut 8x6.5mm	-	9	POA (Exc VAT)			?	0
	Superseded by 16100824	Nut M8 x 6.5	N	9	£0.13 (Exc VAT)				0
15	11198071	Washer Beville 8mm	-	9	POA (Exc VAT)			?	0
	Superseded by 11198074	Washer 8mm	N	9	£0.06 (Exc VAT)				0
16	108384	Head Gasket	-	2	POA (Exc VAT)			?	0
	Superseded by 168946	Cylinder Head Gasket	MP N	2	£480.71 (Exc VAT)				0
17	110021	Sealing Ring In alternativa n. 102797	MP -	8	£7.68 (Exc VAT)				0
18	13953521	Stud	-	5	POA (Exc VAT)			?	0
19	12164711	Nut M10 x 1.25 x 8	-	5	£0.21 (Exc VAT)				0
20	12601471	Washer	-	5	POA (Exc VAT)			?	0
	Superseded by 12601474	Wavy Washer 10mm	N	5	£0.03 (Exc VAT)				0
21	11500621	Stud 6 x 9 Stem 25	-	6	POA (Exc VAT)			?	0
22	15896211	Nut M6 x 5	-	6	£0.06 (Exc VAT)				0
23	11197771	Washer	-	6	POA (Exc VAT)			?	0
	Superseded by 11197774	Conic Washer 6.4x12x1.2	N	6	£0.05 (Exc VAT)				0
24	13517321	Threaded Stud	-	6	£17.75 (Exc VAT)				0
25	13517421	Stud	-	1	POA (Exc VAT)			?	0
26	13518221	Stud	-	1	£0.70 (Exc VAT)				0
27	16104411	Nyloc Nut M8 x 8.5	-	8	£0.17 (Exc VAT)			?	0
	Alternative 104030	Nyloc Nut M8 x 1.25 x 9.5	N	8	£0.21 (Exc VAT)				0
28	12601371	Washer	-	8	POA (Exc VAT)			?	0
	Superseded by 12601374	Wavy Washer 8mm	N	8	£0.02 (Exc VAT)				0
29	102704	Dowel	-	2	£2.59 (Exc VAT)				0
30	103830	Heli Coil	-	4	£2.95 (Exc VAT)				0
31	109294	Mains Bearing Cap Non vole per GTS e AUS - Col basamento completo	-	1	POA (Exc VAT)			?	0
32	13543821	Stud M8 x 16 Gambo 40 Non vale per GTS e AUS	-	1	£1.99 (Exc VAT)			?	0
	Superseded by 13543824	Stud Bolt 8x16 -Shank length 40mm-	N	1	£2.69 (Exc VAT)				0
33	13517221	Threaded Stud	-	3	POA (Exc VAT)			?	0
34	16104411	Nyloc Nut M8 x 8.5	-	3	£0.17 (Exc VAT)			?	0
35	12601371	Washer	-	3	POA (Exc VAT)			?	0
36	107923	Stud Dopo esaur. vale n. 115237	-	2	POA (Exc VAT)			?	0
37	102742	Nyloc Nut M10x1.25x10	-	2	£0.34 (Exc VAT)				0
38	12601471	Washer	-	2	POA (Exc VAT)			?	0
39	104657	Heli Coil	-	2	POA (Exc VAT)			?	0
40	14326150	Threaded Plug 8x1.25	-	1	£0.47 (Exc VAT)			?	0
41	103843	RH Threaded Stud Non vale per GTS e AUS	-	2	POA (Exc VAT)			?	0
42	10275001	Plug	-	2	£2.37 (Exc VAT)				0
43	10263460	Gasket	-	2	£0.30 (Exc VAT)				0
44	10269850	Threaded Plug D. 22 x 11	-	2	£1.59 (Exc VAT)				0
45	10269950	Plug	MP -	2	POA (Exc VAT)			?	0
46	103948	Radiator Drain Tap 14x1.5mm	MP -	1	POA (Exc VAT)			?	0
	Alternative 103948/B	Radiator Drain Tap 14x1.5mm	MP N	1	£133.25 (Exc VAT)				0
47	100511	Washer	-	1	POA (Exc VAT)			?	0
	Superseded by 10280060	Copper Washer 14 - 20 x 1.5mm	N	1	£0.17 (Exc VAT)				0
48	109663	Front Cover GTB Vale per GTB fino al rnotore n. 01 105. Non vale per AUS	-	1	POA (Exc VAT)			?	0
48	112864	Front Cover GTB Vale per GTB dal motore n.01106. Non vale per AUS	-	1	POA (Exc VAT)			?	0
48	107588	Front Cover GTS Vale per GTS e AUS. Fino al motore n. 03044 GTS e2982 AUS	-	1	POA (Exc VAT)			?	0
48	112473	Front Cover GTS Vale per GTS e AUS dal motore n. 03045 GTS e 02983 AUS	-	1	POA (Exc VAT)			?	0
49	103791	Front Cover Gasket	-	1	POA (Exc VAT)			?	0
	Superseded by 135089	Front Cover Gasket	MP N	1	£17.05 (Exc VAT)				0
50	108224	Oil Seal In alternaliva n. 105231	MP -	1	£20.37 (Exc VAT)			?	0
51	12354521	Stud Per GTS e AUS q = 6	-	5	POA (Exc VAT)			?	0
	Superseded by 12354524	Stud M8 x 16 Gambo 22mm	N	5	£24.99 (Exc VAT)				0
52	16100811	Nut 8x6.5mm	-	6	POA (Exc VAT)			?	0
53	11198071	Washer Beville 8mm	-	6	POA (Exc VAT)			?	0
54	103039	O-Ring	MP -	2	£0.75 (Exc VAT)				0
55	13546221	Stud Bolt	-	2	POA (Exc VAT)			?	0
	Superseded by 13546224	Stud	N	2	£12.99 (Exc VAT)				0
56	12164711	Nut M10 x 1.25 x 8	-	2	£0.21 (Exc VAT)				0
57	12601471	Washer	-	2	POA (Exc VAT)			?	0
58	103588	Cylinder Liner	MP -	8	£412.97 (Exc VAT)				0

Make an Enquiry Report an Issue

Part Availability Key

In Stock

In Stock - Supersession (Supersession price shown)

In Stock - Alternative (Alternative price shown)

In Stock - Partial Stock

Enquire

Recently Viewed

Ferrari / 308 GTB/GTS Carburetor / 002 - Crankcase
